Single Row Deep Groove Ball Bearings 6210/W64

Single Row Deep Groove Ball Bearings 6210/W64

The 6210/W64 is a single-row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 7891 lbf and operates smoothly at speeds up to 7100 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage offers durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 463g, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6210/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 7891 lbf
  • Static Radial Load 5238 lbf
  • Max Speed 7100 rpm
  • Weight 463 g
  • price（$） 17.244
Single Row Deep Groove Ball Bearings 6210/W64 dimension drawing
Download DWG Download PDF

Features

How Does 6210/W64 Bearing Reduce Friction?

6210/W64 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability and reduces friction during operation.
Solid oil lubrication maintains consistent performance, even at speeds up to 7,100 rpm.
Its ABEC 1 tolerance class guarantees reliable precision in various applications.

Application

Industrial Uses of 6210/W64 Bearing
The 6210/W64 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its solid oil lubrication reduces maintenance needs, making it suitable for continuous operation.

Where Is 6210/W64 Bearing Used?
You’ll often find the 6210/W64 Bearing in automotive applications such as alternators and wheel hubs, thanks to its durable chrome steel construction. The open design allows for easy inspection and lubrication in high-demand environments.

Perfect Fit for Automation: 6210/W64 Bearing
In robotics and automated systems, the 6210/W64 Bearing provides smooth motion control for components like conveyor belts. Its ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Medical vs Industrial: Where 6210/W64 Bearing Excels
While the 6210/W64 Bearing handles industrial loads well, it’s also found in medical devices like centrifuges due to its stable operation. The wide temperature range makes it adaptable to various environments.

Key Fields for 6210/W64 Bearing
Household appliances like washing machines benefit from the 6210/W64 Bearing’s quiet operation and long service life. The metric sizing ensures compatibility with a range of consumer products.
