Single Row Deep Groove Ball Bearings 6207-2Z/C3 GJN

Single Row Deep Groove Ball Bearings 6207-2Z/C3 GJN

The 6207-2Z/C3 GJN is a single-row deep groove ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5778 lbf and operates smoothly at speeds up to 9200 RPM.

Its shielded design keeps dirt out while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Perfect for applications like electric motors or pumps where radial loads are common.

Weighing just 288g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6207-2Z/C3 GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 5778 lbf
  • Static Radial Load 3462 lbf
  • Max Speed 9200 rpm
  • Weight 288 g
  • price（$） 4.986
Single Row Deep Groove Ball Bearings 6207-2Z/C3 GJN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6207-2Z/C3 GJN Bearing

6207-2Z/C3 GJN Bearing is designed for radial loads with a dynamic capacity of 5778 lbf, ensuring reliable performance.

The shielded design protects against contaminants, making it suitable for various industrial applications.

With chrome steel rings and balls, it offers durability and resistance to wear.

Its maximum speed of 9,200 rpm allows for efficient operation in high-speed environments.

Application

Common Applications of 6207-2Z/C3 GJN Bearing
In industrial settings, 6207-2Z/C3 GJN Bearing is widely used in electric motors and pumps, where its shielded design protects against dust and debris. The C3 clearance ensures reliable performance even under varying thermal conditions.

Where Is 6207-2Z/C3 GJN Bearing Used?
You’ll often find 6207-2Z/C3 GJN Bearing in automotive applications like alternators and water pumps, thanks to its radial load capacity. Its chrome steel construction offers durability in high-speed environments.

Built for Heavy-Duty Use: 6207-2Z/C3 GJN Bearing
For conveyor systems and gearboxes, 6207-2Z/C3 GJN Bearing provides smooth operation under consistent radial loads. The metric sizing makes it easy to integrate into various machinery designs.

Light-Duty vs Heavy-Duty: Best Uses for 6207-2Z/C3 GJN Bearing
In light-duty applications like household appliances, 6207-2Z/C3 GJN Bearing ensures quiet and efficient performance. For heavier tasks, its robust design handles industrial equipment with ease.
