Single Row Deep Groove Ball Bearings 6206 TN9/C3VQ488

Single Row Deep Groove Ball Bearings 6206 TN9/C3VQ488

The 6206 TN9/C3VQ488 is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4384 lbf and operates smoothly at speeds up to 11000 RPM.

Its open design and nylon cage provide durability and easy maintenance, while the C3 radial clearance ensures reliable performance under varying conditions. The bearing works efficiently in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 199g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6206 TN9/C3VQ488
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 199 g
Single Row Deep Groove Ball Bearings 6206 TN9/C3VQ488 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6206 TN9/C3VQ488 Bearing

6206 TN9/C3VQ488 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 4384 lbf.
Its nylon cage ensures smooth operation and reduces friction during high-speed rotations.
The C3 radial clearance allows for thermal expansion, making it suitable for varied temperature conditions.
With a maximum speed of 11,000 rpm, it delivers reliable performance in diverse applications.

Application

Industrial Uses of 6206 TN9/C3VQ488 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its single-row design handles radial loads efficiently. The open seal allows for easy lubrication, extending service life in demanding conditions.

How Does 6206 TN9/C3VQ488 Bearing Improve Performance?
In automotive applications, it supports components such as alternators and fans, ensuring smooth rotation with minimal friction. The C3 clearance provides flexibility for thermal expansion in high-temperature environments.

Perfect Fit for Automation: 6206 TN9/C3VQ488 Bearing
Its nylon cage reduces noise, making it ideal for robotic arms and conveyor systems in automated production lines. The chrome steel construction offers durability for continuous operation.

Medical vs Industrial: Where 6206 TN9/C3VQ488 Bearing Excels
While it performs reliably in industrial gearboxes, its precision also suits medical devices like centrifuges. The balanced load capacity ensures consistent performance across different applications.

Essential Roles of 6206 TN9/C3VQ488 Bearing
In household appliances like washing machines, this bearing provides quiet and efficient operation. Its metric sizing ensures compatibility with a wide range of consumer products.
