Single Row Deep Groove Ball Bearings 6206-2Z/VP1760

The 6206-2Z/VP1760 is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4384 lbf and spins efficiently at speeds up to 11000 RPM.

Its shielded design keeps out dust and debris, while the chrome steel cage ensures durability. The bearing operates smoothly in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or small machinery where radial loads are common.

Weighing just 199g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6206-2Z/VP1760
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 30 mm
Bore Dia Tolerance -0.01mm to 0
Outer Dia 62 mm
Outer Dia Tolerance -0.013mm to 0
Width 16 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 4384 lbf
Static Radial Load 254 lbf
Max Speed 11000 rpm
Weight 199 g

Single Row Deep Groove Ball Bearings 6206-2Z/VP1760 dimension drawing

Download DWG Download PDF

Features

How Does 6206-2Z/VP1760 Bearing Reduce Friction?

6206-2Z/VP1760 Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The shielded seal protects against contaminants while maintaining low friction during operation.

Made from chrome steel, 6206-2Z/VP1760 Bearing offers durability and consistent performance.
Its ABEC 1 tolerance ensures reliable precision in various applications.

With a dynamic radial load capacity of 4384 lbf, 6206-2Z/VP1760 Bearing handles demanding conditions effortlessly.
The design also supports speeds up to 11,000 rpm for efficient operation.

6206-2Z/VP1760 Bearing operates in temperatures from -30°C to 120°C, adapting to diverse environments.
Its compact size (30 mm×62 mm×16 mm) makes it suitable for space-constrained installations.

Application

Common Applications of 6206-2Z/VP1760 Bearing
In industrial settings, 6206-2Z/VP1760 Bearing is widely used in electric motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

How Does 6206-2Z/VP1760 Bearing Improve Performance?
For automotive applications like alternators and wheel hubs, 6206-2Z/VP1760 Bearing offers smooth rotation and reliable load handling. Its ABEC 1 tolerance makes it a cost-effective choice without compromising performance.

Built for Heavy-Duty Use: 6206-2Z/VP1760 Bearing
In agricultural machinery, 6206-2Z/VP1760 Bearing handles radial loads efficiently, thanks to its deep groove design. The wide temperature range also makes it suitable for outdoor equipment exposed to varying weather conditions.

Automotive vs Industrial: Where 6206-2Z/VP1760 Bearing Excels
While 6206-2Z/VP1760 Bearing performs well in car components, it’s equally at home in conveyor systems and gearboxes. The metric sizing ensures compatibility with a broad range of machinery across different sectors.

Perfect Fit for Automation: 6206-2Z/VP1760 Bearing
In robotic arms and automated assembly lines, 6206-2Z/VP1760 Bearing provides precise movement with minimal maintenance. The shielded seals help extend service life by reducing dust and debris ingress.
