Single Row Deep Groove Ball Bearings 6206-2Z/C3LHT55

Single Row Deep Groove Ball Bearings 6206-2Z/C3LHT55

The 6206-2Z/C3LHT55 is a single-row deep groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 4384 lbf and can spin at speeds up to 11000 RPM.

Its shielded design keeps dirt out while the C3 radial clearance ensures smooth operation under varying temperatures. The bearing works reliably in conditions from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or small machinery where consistent radial load support is needed.

Weighing just 199g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6206-2Z/C3LHT55
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 254 lbf
  • Max Speed 11000 rpm
  • Weight 199 g
  • price（$） 3.276
Single Row Deep Groove Ball Bearings 6206-2Z/C3LHT55 dimension drawing
Download DWG Download PDF

Features

How Does 6206-2Z/C3LHT55 Bearing Reduce Friction?

6206-2Z/C3LHT55 Bearing features a single-row deep groove design, optimised for smooth radial load handling.
Its chrome steel construction ensures durability while minimising friction during operation.

The shielded design of 6206-2Z/C3LHT55 Bearing protects against contaminants, maintaining performance.
With a maximum speed of 11,000 rpm, it delivers reliable efficiency in various applications.

6206-2Z/C3LHT55 Bearing operates in temperatures from -30°C to 120°C, suitable for diverse environments.
Its C3 radial clearance provides flexibility, accommodating thermal expansion during use.

The chrome steel cage in 6206-2Z/C3LHT55 Bearing keeps balls aligned, reducing wear over time.
This design choice extends service life while maintaining consistent performance.

At 199g, 6206-2Z/C3LHT55 Bearing offers a balance between strength and manageable weight.
Its compliant status with RoHS and REACH standards ensures environmental responsibility.

Application

Industrial Uses of 6206-2Z/C3LHT55 Bearing
The 6206-2Z/C3LHT55 Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. Its C3 radial clearance allows for thermal expansion, making it suitable for variable operating conditions.

In automotive applications, 6206-2Z/C3LHT55 Bearing fits well in wheel hubs and alternators, providing reliable radial load support. The chrome steel construction ensures durability even under constant vibration and stress.

For automation systems, 6206-2Z/C3LHT55 Bearing works efficiently in conveyor belts and robotic arms, thanks to its smooth operation. The ABEC 1 tolerance ensures consistent performance without requiring frequent maintenance.

In household appliances like washing machines, 6206-2Z/C3LHT55 Bearing offers quiet and long-lasting performance. Its metric sizing makes it easy to replace in most European and Asian models.
