Single Row Deep Groove Ball Bearings 6205/VK285

Single Row Deep Groove Ball Bearings 6205/VK285

The 6205/VK285 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3147 lbf and operates smoothly at speeds up to 13,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 128g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205/VK285
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
Single Row Deep Groove Ball Bearings 6205/VK285 dimension drawing
Download DWG Download PDF

Features

Engineered for Precision: 6205/VK285 Bearing

6205/VK285 Bearing features chrome steel rings and balls, ensuring durability and smooth operation.
Its single-row deep groove design provides excellent radial load capacity, up to 3147 lbf.

The ABEC 1 tolerance class ensures reliable performance for various applications.
With a maximum speed of 13,000 rpm, it balances efficiency and longevity.

6205/VK285 Bearing operates in temperatures from -30°C to 120°C, suitable for diverse environments.
Its open seal design allows for easy maintenance and lubrication.

Application

Common Applications of 6205/VK285 Bearing
In industrial settings, 6205/VK285 Bearing is commonly used in electric motors and pumps, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, extending service life in demanding conditions.

Where Is 6205/VK285 Bearing Used?
You’ll often find 6205/VK285 Bearing in automotive applications like alternators and water pumps, thanks to its balanced radial load handling. Its chrome steel construction also makes it suitable for moderate-speed operations.

Built for Versatility: 6205/VK285 Bearing
For household appliances like washing machines, 6205/VK285 Bearing provides smooth rotation with minimal noise. The ABEC 1 tolerance ensures consistent performance without over-engineering for everyday use.

Light-Duty vs Heavy-Duty: Best Uses for 6205/VK285 Bearing
In light-duty applications such as office printers, 6205/VK285 Bearing offers quiet operation and durability. For heavier tasks like conveyor rollers, its dynamic load rating handles continuous use effectively.

Why Is 6205/VK285 Bearing Essential in Machinery?
With a max speed of 13,000 rpm, 6205/VK285 Bearing works well in small machinery requiring efficient radial load support. The ISO P0 tolerance makes it a cost-effective choice for general-purpose equipment.
