Single Row Deep Groove Ball Bearings 6205/VK284

Single Row Deep Groove Ball Bearings 6205/VK284

The 6205/VK284 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3147 lbf and can spin at speeds up to 13,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable alternative for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing just 128g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205/VK284
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
Single Row Deep Groove Ball Bearings 6205/VK284 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205/VK284 Bearing

6205/VK284 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3147 lbf, ensuring reliable performance in various applications.

The single-row deep groove design enhances stability and reduces friction during operation.
With a maximum speed of 13,000 rpm, it delivers both durability and efficiency.

6205/VK284 Bearing operates smoothly in temperatures ranging from -30°C to 120°C.
Its open seal type allows for easy maintenance and lubrication when needed.

The ABEC 1 tolerance class ensures consistent performance in standard precision applications.
Weighing just 128 grams, it combines strength with a lightweight design.

Application

Industrial Uses of 6205/VK284 Bearing
The 6205/VK284 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. Its open design allows for easy lubrication, making it suitable for high-speed applications.

In automotive systems, 6205/VK284 Bearing fits well in components such as alternators and wheel hubs, providing reliable performance under varying loads. The metric sizing ensures compatibility with a wide range of vehicle models.

For automation equipment, 6205/VK284 Bearing’s chrome steel construction offers durability in robotic arms and conveyor systems. Its ABEC 1 tolerance class ensures consistent performance in precision-driven tasks.

Around the home, 6205/VK284 Bearing can be found in appliances like washing machines and fans, where its quiet operation and long lifespan are appreciated. The temperature range makes it adaptable to different environments.
