Single Row Deep Groove Ball Bearings 6205 TN9/C3

Single Row Deep Groove Ball Bearings 6205 TN9/C3

The 6205 TN9/C3 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13000 RPM.

Its open design and nylon cage provide durability while allowing easy maintenance. The bearing operates well in temperatures from -30°C to 120°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing just 128g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205 TN9/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 2.961
Single Row Deep Groove Ball Bearings 6205 TN9/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205 TN9/C3 Bearing

6205 TN9/C3 Bearing is built with chrome steel rings and balls, offering reliable radial load support up to 3147 lbf.
Its nylon cage ensures smooth operation and reduces friction, enhancing efficiency.
The C3 radial clearance allows for thermal expansion, making it suitable for varied temperature conditions.
With a maximum speed of 13,000 rpm, it delivers consistent performance in high-speed applications.

Application

Key Fields for 6205 TN9/C3 Bearing
The 6205 TN9/C3 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures reliable performance. Its open design and nylon cage make it suitable for moderate-speed applications.

How Does 6205 TN9/C3 Bearing Improve Performance?
In automotive applications, the 6205 TN9/C3 Bearing supports components like alternators and water pumps, providing smooth rotation under radial loads. The C3 clearance allows for thermal expansion, making it adaptable to varying temperatures.

Built for Heavy-Duty Use: 6205 TN9/C3 Bearing
For automation systems, the 6205 TN9/C3 Bearing is a dependable choice for conveyor belts and robotic arms, thanks to its chrome steel construction. Its lightweight design also helps reduce energy consumption in continuous operations.

Light-Duty vs Heavy-Duty: Best Uses for 6205 TN9/C3 Bearing
In consumer electronics like printers and small appliances, the 6205 TN9/C3 Bearing offers quiet and efficient operation. For heavier tasks, its robust design handles radial loads in industrial gearboxes without compromising performance.
