Single Row Deep Groove Ball Bearings 6205-2RSH/HC5C3GJN

Single Row Deep Groove Ball Bearings 6205-2RSH/HC5C3GJN

The 6205-2RSH/HC5C3GJN is a sealed single row deep groove ball bearing, measuring 25mm by 52mm by 15mm. Made from chrome steel with silicon nitride balls, it offers a good balance of strength and smooth operation.

It handles radial loads up to 3147 lbf and can spin at speeds up to 13,000 RPM, making it suitable for high-speed applications. The sealed design keeps out dust and dirt, reducing maintenance needs.

With a C3 radial clearance, it accommodates slight misalignments and thermal expansion. The bearing performs well in temperatures from -30°C to 120°C.

Ideal for electric motors, pumps, or small machinery, this model is interchangeable with SKF bearings. Weighing just 128g, it’s lightweight yet durable for everyday industrial use. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RSH/HC5C3GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Silicon Nitride(Si3N4)
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 45.873
Single Row Deep Groove Ball Bearings 6205-2RSH/HC5C3GJN dimension drawing
Download DWG Download PDF

Features

How Does 6205-2RSH/HC5C3GJN Bearing Reduce Friction?

6205-2RSH/HC5C3GJN Bearing features silicon nitride balls, which significantly lower friction during operation.
The sealed design helps retain lubrication, ensuring smooth performance over extended periods.

With a dynamic radial load capacity of 3147 lbf, it handles demanding radial loads efficiently.
Its chrome steel rings and cage provide durability, even in high-speed applications.

The bearing operates smoothly at temperatures ranging from -30°C to 120°C.
Its C3 radial clearance ensures optimal performance under varying thermal conditions.

The ABEC 1 precision rating makes it suitable for general industrial use.
Weighing just 128 g, it offers a good balance of strength and lightweight design.

Application

Common Applications of 6205-2RSH/HC5C3GJN Bearing
6205-2RSH/HC5C3GJN Bearing is widely used in industrial machinery, such as electric motors and pumps, where its sealed design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

In automotive applications, 6205-2RSH/HC5C3GJN Bearing is often found in alternators and wheel hubs, providing reliable performance with minimal maintenance. Its silicon nitride balls reduce friction, making it suitable for high-speed rotations.

For household appliances like washing machines, 6205-2RSH/HC5C3GJN Bearing offers quiet and efficient operation. The chrome steel construction ensures durability, even with frequent use.

In automation systems, 6205-2RSH/HC5C3GJN Bearing supports robotic arms and conveyor belts, where precision and reliability are key. The sealed design also protects against dust and debris in demanding environments.
