Single Row Deep Groove Ball Bearings 6205-2RSH/C3

Single Row Deep Groove Ball Bearings 6205-2RSH/C3

The 6205-2RSH/C3 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Sealed on both sides, it keeps dirt out and grease in, making it low-maintenance. The C3 clearance allows for slight expansion under heat, ideal for varied temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. Perfect for electric motors, pumps, or gearboxes where reliability is key.

Weighing just 128g, it’s lightweight yet sturdy, complying with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RSH/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 3.465
Single Row Deep Groove Ball Bearings 6205-2RSH/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6205-2RSH/C3 Bearing

6205-2RSH/C3 Bearing is designed for radial loads, with a dynamic radial load capacity of 3147 lbf.
Its sealed construction keeps contaminants out, ensuring smooth operation in various environments.

The chrome steel rings and balls provide durability, while the C3 radial clearance allows for thermal expansion.
With a maximum speed of 13,000 rpm, it offers reliable performance in high-speed applications.

6205-2RSH/C3 Bearing operates in temperatures from -30°C to 120°C, making it versatile for different conditions.
Its sealed design reduces maintenance needs, saving time and effort.

The ABEC 1 tolerance ensures consistent performance, suitable for general industrial use.
At 128 grams, it is lightweight yet robust for its size.

Application

Common Applications of 6205-2RSH/C3 Bearing
The 6205-2RSH/C3 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its sealed design helps keep out dust and moisture. Its C3 clearance ensures reliable performance even under varying thermal conditions.

In automotive applications, 6205-2RSH/C3 Bearing fits well in wheel hubs and alternators, providing smooth rotation and long service life. The chrome steel construction adds durability, making it suitable for both passenger and commercial vehicles.

For household appliances like washing machines and fans, 6205-2RSH/C3 Bearing offers quiet operation and low maintenance. Its metric sizing makes it easy to replace in a variety of European and Asian brands.

Where Is 6205-2RSH/C3 Bearing Used?
You’ll often find 6205-2RSH/C3 Bearing in conveyor systems, where its radial load capacity handles constant movement effortlessly. The sealed design also reduces the need for frequent lubrication.

In robotics, 6205-2RSH/C3 Bearing ensures precise movement in joints and actuators, thanks to its consistent performance. The ABEC 1 tolerance makes it a cost-effective choice for many automated systems.
