Single Row Deep Groove Ball Bearings 6205-2RSH/C2

Single Row Deep Groove Ball Bearings 6205-2RSH/C2

The 6205-2RSH/C2 is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance, while the C2 radial clearance ensures reliable performance. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative. Perfect for electric motors or pumps where radial loads and moderate speeds are common.

Weighing just 128g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RSH/C2
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C2
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 3.465
Single Row Deep Groove Ball Bearings 6205-2RSH/C2 dimension drawing
Download DWG Download PDF

Features

Why Choose 6205-2RSH/C2 Bearing for Precision Tasks?

6205-2RSH/C2 Bearing features sealed construction, protecting against dust and moisture for consistent performance.
Its chrome steel rings and balls offer reliable radial load support, with a dynamic capacity of 3147 lbf.

The C2 radial clearance ensures smooth operation, even at high speeds up to 13,000 rpm.
With a temperature range of -30°C to 120°C, it performs well in various environments.

Maintenance is minimal due to its sealed design, reducing long-term operational costs.
The compact 25 mm×52 mm×15 mm size makes it ideal for space-constrained applications.

Application

Common Applications of 6205-2RSH/C2 Bearing
The 6205-2RSH/C2 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its sealed design helps keep contaminants out. Its chrome steel construction ensures durability in demanding environments.

In automotive applications, 6205-2RSH/C2 Bearing is often found in wheel hubs and alternators, providing reliable performance under radial loads. The C2 clearance makes it suitable for applications requiring tighter tolerances.

For household appliances like washing machines and fans, 6205-2RSH/C2 Bearing offers quiet and smooth operation. Its sealed design reduces the need for frequent maintenance, making it a convenient choice for everyday use.

In automation systems, 6205-2RSH/C2 Bearing supports robotic arms and conveyor belts, where consistent performance is key. The metric sizing ensures compatibility with a variety of equipment.
