Single Row Deep Groove Ball Bearings 6205-2RS/C3 GJN

Single Row Deep Groove Ball Bearings 6205-2RS/C3 GJN

The 6205-2RS/C3 GJN is a single-row deep groove ball bearing with a 25mm bore and 52mm outer diameter, crafted from sturdy chrome steel for lasting performance. It handles radial loads up to 3147 lbf and spins smoothly at speeds up to 13,000 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs, while the C3 clearance ensures reliable operation under varying temperatures. The bearing works well in environments ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where consistent radial load support is needed.

Weighing just 128g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6205-2RS/C3 GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3147 lbf
  • Static Radial Load 1765 lbf
  • Max Speed 13000 rpm
  • Weight 128 g
  • price（$） 4.212
Single Row Deep Groove Ball Bearings 6205-2RS/C3 GJN dimension drawing
Download DWG Download PDF

Features

How Does 6205-2RS/C3 GJN Bearing Reduce Friction?

6205-2RS/C3 GJN Bearing features a deep groove design, optimised for smooth radial load distribution.

The sealed construction keeps contaminants out, ensuring consistent performance over time.

With chrome steel rings and balls, it offers reliable operation in temperatures from -30°C to 120°C.

Its C3 radial clearance allows for thermal expansion, making it suitable for varied applications.

Application

Common Applications of 6205-2RS/C3 GJN Bearing
The 6205-2RS/C3 GJN Bearing is widely used in industrial machinery, such as electric motors and pumps, where its sealed design helps keep contaminants out. Its C3 radial clearance ensures smooth operation even under varying thermal conditions.

In automotive applications, 6205-2RS/C3 GJN Bearing is commonly found in alternators and wheel hubs, providing reliable radial load support. The chrome steel construction offers durability, making it suitable for long-term use in vehicles.

For household appliances like washing machines, 6205-2RS/C3 GJN Bearing ensures quiet and efficient operation. The sealed design prevents dust and moisture from affecting performance, extending the bearing’s lifespan.

In automation systems, 6205-2RS/C3 GJN Bearing is often used in conveyor belts and robotic arms. Its high-speed capability and consistent performance make it a dependable choice for repetitive motion tasks.
