Single Row Deep Groove Ball Bearings 6204/C3MT

Single Row Deep Groove Ball Bearings 6204/C3MT

The 6204/C3MT is a single-row deep groove ball bearing with a 20mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2878 lbf and spins efficiently at speeds up to 15,000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing operates smoothly in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it’s suited for applications where slight expansion or misalignment might occur. Ideal for use in electric motors, pumps, or small machinery requiring reliable radial load support.

Weighing just 106g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6204/C3MT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 14 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2878 lbf
  • Static Radial Load 1495 lbf
  • Max Speed 15000 rpm
  • Weight 106 g
Single Row Deep Groove Ball Bearings 6204/C3MT dimension drawing
Download DWG Download PDF

Features

Performance Features of 6204/C3MT Bearing

6204/C3MT Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 2878 lbf.

Its C3 radial clearance ensures smooth operation, even under varying temperature conditions.

The open design allows for easy lubrication, making it suitable for high-speed applications up to 15,000 rpm.

With a temperature range of -30°C to 120°C, it performs reliably in diverse environments.

Application

Common Applications of 6204/C3MT Bearing
The 6204/C3MT Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures reliable performance. Its open design and C3 clearance make it suitable for applications with thermal expansion or misalignment.

In automotive systems, you’ll find 6204/C3MT Bearing in components like alternators and wheel hubs, thanks to its durability and smooth operation. The metric sizing ensures compatibility with a variety of vehicle models.

For automation and robotics, 6204/C3MT Bearing provides precise motion control in devices like conveyor belts and robotic arms. The chrome steel construction offers long-lasting performance even in high-speed scenarios.

Around the home, 6204/C3MT Bearing can be spotted in appliances like washing machines and fans, where its quiet operation and reliability are appreciated. The lightweight design also makes it easy to integrate into compact spaces.
