Single Row Deep Groove Ball Bearings 6204-2ZTN9/C3/R806

Single Row Deep Groove Ball Bearings 6204-2ZTN9/C3/R806

The 6204-2ZTN9/C3/R806 is a single-row deep groove ball bearing with a 20mm bore and 47mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 2878 lbf and spins smoothly at speeds up to 15,000 RPM.

Shielded on both sides, it keeps dirt out while the nylon cage reduces friction for quieter operation. The C3 radial clearance allows for slight misalignment or thermal expansion.

This bearing works well in temperatures from -30°C to 120°C, making it suitable for motors or pumps. Weighing just 106g, it’s lightweight yet robust for its size.

Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement in industrial or automotive applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6204-2ZTN9/C3/R806
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 14 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2878 lbf
  • Static Radial Load 1495 lbf
  • Max Speed 15000 rpm
  • Weight 106 g
Single Row Deep Groove Ball Bearings 6204-2ZTN9/C3/R806 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6204-2ZTN9/C3/R806 Bearing

6204-2ZTN9/C3/R806 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 2878 lbf, making it suitable for various applications.

The shielded design of 6204-2ZTN9/C3/R806 Bearing protects against dust and contaminants.
This ensures smooth operation and reduces maintenance needs over time.

With a maximum speed of 15,000 rpm, 6204-2ZTN9/C3/R806 Bearing balances speed and durability.
The nylon cage helps reduce friction and noise during operation.

6204-2ZTN9/C3/R806 Bearing operates efficiently in temperatures from -30°C to 120°C.
Its C3 radial clearance provides flexibility in different operating conditions.

Application

Industrial Uses of 6204-2ZTN9/C3/R806 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design protects against dust and debris. The C3 clearance ensures reliable performance even under moderate radial loads.

What Makes 6204-2ZTN9/C3/R806 Bearing a Preferred Choice?
Its nylon cage reduces friction and noise, making it ideal for applications requiring quiet operation, such as office equipment or household appliances. The chrome steel construction also offers good durability for long-term use.

Perfect Fit for Automation: 6204-2ZTN9/C3/R806 Bearing
In robotic arms and conveyor systems, this bearing handles radial loads smoothly while maintaining precision. The metric sizing ensures compatibility with a wide range of machinery components.

Automotive vs Industrial: Applications of 6204-2ZTN9/C3/R806 Bearing
In automotive systems like alternators, it provides steady performance, while in industrial gearboxes, its high-speed capability stands out. The temperature range suits both environments well.

Where Is 6204-2ZTN9/C3/R806 Bearing Used?
You’ll find it in small appliances like fans or power tools, where its compact size and shielded design are advantageous. The ABEC 1 tolerance is sufficient for most everyday applications.
