Single Row Deep Groove Ball Bearings 6200/C3MTVK016

Single Row Deep Groove Ball Bearings 6200/C3MTVK016

The 6200/C3MTVK016 is a compact single row deep groove ball bearing, measuring 10mm by 30mm by 9mm. Made from chrome steel, it’s built to handle radial loads up to 1147 lbf and can spin at speeds up to 24,000 RPM.

Its open design and C3 radial clearance allow for smooth operation, even in varying temperatures from -30°C to 120°C. The chrome steel cage adds durability, making it a reliable choice for long-term use.

This bearing is interchangeable with SKF models, simplifying replacements. It’s ideal for applications like electric motors or small machinery where space is limited but performance is key.

Weighing just 32g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it’s a safe and practical option for various industrial needs.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6200/C3MTVK016
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 10 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 30 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 24000 rpm
  • Weight 32 g
Single Row Deep Groove Ball Bearings 6200/C3MTVK016 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6200/C3MTVK016 Bearing

6200/C3MTVK016 Bearing is built with chrome steel rings and balls, offering strong radial load capacity.
Its dynamic radial load reaches 1147 lbf, making it suitable for various applications.

The C3 radial clearance ensures smooth operation even under varying temperatures.
With a maximum speed of 24,000 rpm, it balances performance and durability.

6200/C3MTVK016 Bearing’s open design allows for easy maintenance and lubrication.
Its compact size of 10 mm×30 mm×9 mm makes it ideal for space-constrained installations.

Application

Industrial Uses of 6200/C3MTVK016 Bearing
This bearing is commonly used in electric motors and pumps, where its single-row design handles radial loads efficiently. The open seal allows for easy lubrication, extending service life in continuous operation.

Where Is 6200/C3MTVK016 Bearing Used?
You’ll find it in household appliances like washing machines, where its compact size and reliable performance keep things running smoothly. The chrome steel construction ensures durability even with frequent use.

Built for Versatility: 6200/C3MTVK016 Bearing
It’s a great fit for conveyor systems in factories, thanks to its C3 clearance handling moderate misalignment. The lightweight design also makes it easy to install in tight spaces.

Automotive vs Industrial: Applications of 6200/C3MTVK016 Bearing
In cars, it supports auxiliary units like alternators, while in industrial gearboxes, it manages steady radial loads. The wide temperature range suits both environments perfectly.
