Single Row Deep Groove Ball Bearings 6200-2Z/C3VT376

The 6200-2Z/C3VT376 is a compact single-row deep groove ball bearing, measuring 10mm in bore and 30mm in outer diameter, with a width of just 9mm. Made from durable chrome steel, it handles radial loads up to 1147 lbf and spins smoothly at speeds up to 24,000 RPM.

Its shielded design keeps dirt out while the C3 radial clearance allows for slight thermal expansion. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for small motors, pumps, or appliances where space is limited.

Weighing only 32g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6200-2Z/C3VT376
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 10 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 30 mm
Outer Dia Tolerance -0.009mm to 0
Width 9 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 1147 lbf
Static Radial Load 54 lbf
Max Speed 24000 rpm
Weight 32 g

Single Row Deep Groove Ball Bearings 6200-2Z/C3VT376 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6200-2Z/C3VT376 Bearing

6200-2Z/C3VT376 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 1147 lbf.

Its shielded design provides protection against dust and contaminants, ensuring smooth operation.

The C3 radial clearance allows for thermal expansion, making it suitable for varied temperature conditions.

With a maximum speed of 24,000 rpm, it delivers reliable performance in high-speed applications.

Application

Common Applications of 6200-2Z/C3VT376 Bearing
6200-2Z/C3VT376 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its shielded design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

In automotive applications, 6200-2Z/C3VT376 Bearing fits well in components like alternators and water pumps, thanks to its balanced radial load capacity. Its chrome steel construction offers durability for long-term use in demanding environments.

For home appliances, 6200-2Z/C3VT376 Bearing is a reliable choice in items like washing machines and fans, where quiet operation is essential. The metric sizing makes it easy to replace in most standard designs.

Where Is 6200-2Z/C3VT376 Bearing Used?
You’ll often find 6200-2Z/C3VT376 Bearing in small machinery, such as power tools, where its compact size and shielded seals are ideal. The high-speed capability also makes it suitable for applications needing quick rotations.

In robotics, 6200-2Z/C3VT376 Bearing supports joints and gears, ensuring precise movement with minimal friction. Its temperature range allows it to perform reliably in both indoor and outdoor settings.

Built for Versatility: 6200-2Z/C3VT376 Bearing
6200-2Z/C3VT376 Bearing works well in conveyor systems, handling moderate radial loads with ease. The chrome steel cage adds extra strength, making it a dependable option for continuous operation.

For office equipment like printers, 6200-2Z/C3VT376 Bearing’s smooth rotation helps maintain consistent performance. Its lightweight design also contributes to energy efficiency in small devices.
