Single Row Deep Groove Ball Bearings 61912

The 61912 is a single-row deep groove ball bearing with a 60mm bore and 85mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3709 lbf and operates smoothly at speeds up to 10,000 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing just 0.2kg, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 61912
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Open
Tolerance Class P6
Radial Clearance Trade No CN
Bore Dia 60 mm
Bore Dia Tolerance -0.012mm to 0
Outer Dia 85 mm
Outer Dia Tolerance -0.013mm to 0
Width 13 mm
Width Tolerance -0.15mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Stainless Steel
REACH Compliant
Temperature Range -30° to 120 °C
Dynamic Radial Load 3709 lbf
Static Radial Load 2698 lbf
Max Speed 10000 rpm
Weight 0.2 kg
price（$） 33.624

Single Row Deep Groove Ball Bearings 61912 dimension drawing

Download DWG Download PDF

Features

Performance Features of 61912 Bearing

61912 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 3709 lbf, ensuring reliable performance in various applications.
The stainless steel cage maintains ball alignment, reducing friction and wear.
With a maximum speed of 10,000 rpm, it delivers smooth operation and efficiency.

Application

Industrial Uses of 61912 Bearing
61912 Bearing is commonly used in industrial machinery like pumps and electric motors, where its single-row design handles radial loads efficiently. The open seal type allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 61912 Bearing fits well in components such as alternators and wheel hubs, providing smooth rotation under varying speeds. Its P6 tolerance class ensures consistent performance in precision-driven systems.

For automation equipment, 61912 Bearing’s chrome steel construction offers durability in robotic arms and conveyor systems. The stainless steel cage adds extra resistance to wear, making it reliable for continuous operation.

Where Is 61912 Bearing Used?
You’ll often find 61912 Bearing in household appliances like washing machines, where its radial load capacity handles the spinning drum’s motion. The metric sizing makes it a versatile choice for various European and Asian models.

In medical devices, 61912 Bearing’s stable performance supports equipment like centrifuges, ensuring quiet and precise operation. The temperature range of -30° to 120°C makes it suitable for diverse clinical environments.

Built for Heavy-Duty Use: 61912 Bearing
61912 Bearing excels in construction machinery, where its high dynamic radial load capacity withstands heavy vibrations. The open design simplifies maintenance, even in dusty or humid worksites.

For agricultural equipment, 61912 Bearing’s robust construction handles the rough conditions of tractors and harvesters. Its compatibility with SKF models makes replacements straightforward.

Light-Duty vs Heavy-Duty: Best Uses for 61912 Bearing
In light-duty applications like office printers, 61912 Bearing ensures quiet and efficient paper handling. The compact width of 13 mm fits neatly into space-constrained designs.

For heavier tasks like industrial fans, 61912 Bearing’s dynamic load rating of 3709 lbf guarantees reliable performance. The chrome steel rings and balls provide long-lasting durability.
