Single Row Deep Groove Ball Bearings 61818/W64

Single Row Deep Groove Ball Bearings 61818/W64

The 61818/W64 is a single-row deep groove ball bearing with a 90mm bore and 115mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4384 lbf and operates smoothly at speeds up to 7000 RPM.
Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.
This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for applications like electric motors or pumps where radial loads are predominant.
Weighing 0.28kg, it’s a compact yet robust choice, compliant with RoHS and REACH standards for safe usage.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61818/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 90 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 115 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 13 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 3822 lbf
  • Max Speed 7000 rpm
  • Weight 0.28 kg
Single Row Deep Groove Ball Bearings 61818/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 61818/W64 Bearing

61818/W64 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4384 lbf, making it suitable for various industrial applications.

The solid oil lubrication ensures smooth operation and reduces maintenance requirements.
With a maximum speed of 7,000 rpm, it provides reliable performance in demanding conditions.

61818/W64 Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its open design and ABEC 1 tolerance class ensure consistent performance and easy installation.

Application

Industrial Uses of 61818/W64 Bearing
61818/W64 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The solid oil lubrication reduces maintenance needs, making it ideal for continuous-use environments.

Where Is 61818/W64 Bearing Used?
You’ll find 61818/W64 Bearing in automotive applications such as alternators and fans, where its chrome steel construction handles high speeds reliably. Its ABEC 1 tolerance offers consistent performance without over-engineering.

Built for Heavy-Duty Use: 61818/W64 Bearing
This bearing works well in conveyor systems, thanks to its robust design and solid oil lubrication. The wide temperature range (-30° to 120°C) also makes it suitable for varied climates.

Automotive vs Industrial: Applications of 61818/W64 Bearing
In cars, 61818/W64 Bearing supports components like AC compressors, while in factories, it’s trusted for machinery requiring low-maintenance solutions. The metric sizing ensures compatibility across global equipment.
