Single Row Deep Groove Ball Bearings 61817

Single Row Deep Groove Ball Bearings 61817

The 61817 is a single-row deep groove ball bearing with an 85mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4384 lbf and operates smoothly at speeds up to 7500 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 0.26kg, it balances lightness with strength. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 61817
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 13 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 3732 lbf
  • Max Speed 7500 rpm
  • Weight 0.26 kg
  • price（$） 59.553
Single Row Deep Groove Ball Bearings 61817 dimension drawing
Download DWG Download PDF

Features

Performance Features of 61817 Bearing

61817 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4384 lbf, ensuring reliable performance in various applications.

The stainless steel cage maintains ball alignment, reducing friction and wear.
With a maximum speed of 7,500 rpm, it delivers consistent performance under demanding conditions.

61817 Bearing operates efficiently in temperatures ranging from -30° to 120 °C.
Its open design allows for easy lubrication and maintenance, enhancing longevity.

The precision P6 tolerance ensures smooth operation, making it suitable for high-performance tasks.
Its compact size of 85 mm×110 mm×13 mm fits seamlessly into various machinery setups.

Application

Industrial Uses of 61817 Bearing
61817 Bearing is commonly used in machine tools and conveyor systems, where its single row deep groove design handles radial loads efficiently. The chrome steel construction ensures durability in demanding industrial environments.

What Makes 61817 Bearing a Preferred Choice?
In automotive applications like electric motors and pumps, 61817 Bearing offers reliable performance due to its high-speed capability and precise tolerances. Its open seal design allows for easy lubrication and maintenance.

Perfect Fit for Automation: 61817 Bearing
For robotic arms and automated assembly lines, 61817 Bearing provides smooth operation with minimal friction. The stainless steel cage enhances longevity, even in continuous use scenarios.

Medical vs Industrial: Where 61817 Bearing Excels
While 61817 Bearing is suitable for industrial machinery, its precision also makes it a good fit for medical devices like lab equipment. The P6 tolerance class ensures consistent performance in sensitive applications.

Where Is 61817 Bearing Used?
In household appliances like washing machines and fans, 61817 Bearing ensures quiet and efficient operation. Its compact size and radial load capacity make it ideal for space-constrained designs.
