Single Row Deep Groove Ball Bearings 609-2Z/C3LT

Single Row Deep Groove Ball Bearings 609-2Z/C3LT

The 609-2Z/C3LT is a compact single-row deep groove ball bearing, measuring 9mm in bore and 24mm in outer diameter, with a width of just 7mm. Made from durable chrome steel, it’s built to handle radial loads up to 642 lbf.

Its shielded design keeps dirt out while allowing smooth rotation at speeds up to 32,000 RPM. The C3 radial clearance provides flexibility for thermal expansion in various applications.

This bearing is interchangeable with SKF models, making replacements straightforward. It performs reliably in temperatures from -30°C to 120°C.

Weighing only 14.7g, it’s ideal for small machinery, electric motors, or appliances where space and efficiency matter. Compliant with RoHS and REACH standards for safety.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 609-2Z/C3LT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 9 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 24 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 642 lbf
  • Static Radial Load 260 lbf
  • Max Speed 32000 rpm
  • Weight 14.7 g
Single Row Deep Groove Ball Bearings 609-2Z/C3LT dimension drawing
Download DWG Download PDF

Features

Performance Features of 609-2Z/C3LT Bearing

609-2Z/C3LT Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 642 lbf, ensuring reliable performance in various applications.

The shielded design of 609-2Z/C3LT Bearing protects against dust and contaminants, extending its service life.
With a maximum speed of 32,000 rpm, it balances efficiency and durability for high-speed operations.

609-2Z/C3LT Bearing operates smoothly in temperatures ranging from -30° to 120°C, making it versatile.
Its C3 radial clearance ensures optimal performance under varying thermal conditions.

Application

Common Applications of 609-2Z/C3LT Bearing
This bearing is widely used in small electric motors, such as those found in household appliances like blenders and fans. Its shielded design helps keep out dust and debris, ensuring smoother operation over time.

Where Is 609-2Z/C3LT Bearing Used?
You’ll often spot 609-2Z/C3LT Bearing in office equipment like printers and scanners, where its compact size and radial load capacity are ideal. The C3 clearance also accommodates slight thermal expansion during prolonged use.

Perfect Fit for Automation: 609-2Z/C3LT Bearing
In robotic arms and small conveyor systems, 609-2Z/C3LT Bearing offers reliable performance thanks to its chrome steel construction. The lightweight design (just 14.7g) reduces energy consumption in high-speed applications.

Automotive vs Industrial: Where 609-2Z/C3LT Bearing Excels
While it’s common in car alternators due to its 32,000 rpm limit, 609-2Z/C3LT Bearing also shines in industrial pumps handling moderate radial loads. The -30° to 120°C range suits most operating environments.

Key Fields for 609-2Z/C3LT Bearing
Medical devices like dental handpieces benefit from this bearing’s precision and contamination-resistant shields. Its ABEC 1 tolerance provides consistent performance for delicate instrumentation.
