Single Row Deep Groove Ball Bearings 608-2RSL/C3GWP

Single Row Deep Groove Ball Bearings 608-2RSL/C3GWP

The 608-2RSL/C3GWP is a compact single-row deep groove ball bearing, measuring 8mm by 22mm by 7mm, crafted from durable chrome steel for reliable performance. It handles radial loads up to 630 lbf and spins smoothly at speeds up to 34,000 RPM.

Its sealed design keeps out dust and moisture, extending its lifespan, while the C3 radial clearance ensures smooth operation under varying temperatures. The bearing works well in environments ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors, skateboards, or small machinery where space is limited.

Weighing just 11.8g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 608-2RSL/C3GWP
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 630 lbf
  • Static Radial Load 248 lbf
  • Max Speed 34000 rpm
  • Weight 11.8 g
Single Row Deep Groove Ball Bearings 608-2RSL/C3GWP dimension drawing
Download DWG Download PDF

Features

How Does 608-2RSL/C3GWP Bearing Reduce Friction?

608-2RSL/C3GWP Bearing features a single row deep groove design, optimised for smooth radial load handling.
The sealed construction keeps contaminants out, ensuring consistent performance over time.

Made from chrome steel, 608-2RSL/C3GWP Bearing offers durability and resistance to wear.
Its C3 radial clearance allows for thermal expansion, making it suitable for varied temperatures.

With a maximum speed of 34,000 rpm, 608-2RSL/C3GWP Bearing balances efficiency and reliability.
The ABEC 1 tolerance ensures precise operation for everyday applications.

Application

Where Is 608-2RSL/C3GWP Bearing Used?
You’ll often spot 608-2RSL/C3GWP Bearing in small electric motors, like those in household appliances or power tools. Its sealed design keeps dust out, making it a reliable choice for everyday gadgets.

In robotics, 608-2RSL/C3GWP Bearing helps smooth out movements in joints and wheels, thanks to its deep groove design. The C3 clearance also handles slight misalignments without fuss.

For DIY projects, 608-2RSL/C3GWP Bearing is a go-to for skateboards or fidget spinners, where its compact size and durability shine. The chrome steel construction ensures it can take a bit of rough handling.

Light-Duty vs Heavy-Duty: Best Uses for 608-2RSL/C3GWP Bearing
In light-duty tasks like office printers, 608-2RSL/C3GWP Bearing keeps things running quietly. The sealed design means less maintenance, which is handy for busy workplaces.

For heavier loads in conveyor systems, 608-2RSL/C3GWP Bearing’s radial load capacity steps up. Its temperature range also makes it suitable for environments with slight fluctuations.
