Single Row Deep Groove Ball Bearings 608-2RSL/C2GLD

Single Row Deep Groove Ball Bearings 608-2RSL/C2GLD

The 608-2RSL/C2GLD is a compact single-row deep groove ball bearing, measuring 8mm by 22mm by 7mm. Made from chrome steel, it handles radial loads up to 630 lbf and spins smoothly at speeds up to 34,000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance. The C2 radial clearance ensures smooth operation under light loads.

This bearing works well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Ideal for small machinery, skateboards, or electric motors where space is limited. Weighing just 11.8g, it’s lightweight yet durable for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 608-2RSL/C2GLD
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C2
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 630 lbf
  • Static Radial Load 248 lbf
  • Max Speed 34000 rpm
  • Weight 11.8 g
Single Row Deep Groove Ball Bearings 608-2RSL/C2GLD dimension drawing
Download DWG Download PDF

Features

How Does 608-2RSL/C2GLD Bearing Reduce Friction?

608-2RSL/C2GLD Bearing features a single-row deep groove design, optimised for smooth radial load handling.
Its chrome steel construction ensures durability while reducing friction during operation.

The sealed design of 608-2RSL/C2GLD Bearing protects against contaminants, enhancing performance in various environments.
With a maximum speed of 34,000 rpm, it offers reliable efficiency for high-speed applications.

608-2RSL/C2GLD Bearing’s C2 radial clearance provides stable operation under varying temperatures.
Its lightweight design at 11.8 g makes it suitable for compact and precision equipment.

Application

Common Applications of 608-2RSL/C2GLD Bearing
You’ll often spot 608-2RSL/C2GLD Bearing in skateboards and inline skates, where its sealed design keeps dirt out while handling radial loads smoothly.

Its compact 8mm bore makes it handy for small electric motors in appliances like desk fans or power tools. The chrome steel construction holds up well to daily wear.

In 3D printers, 608-2RSL/C2GLD Bearing keeps filament spools rotating evenly thanks to its C2 clearance. The sealed feature prevents dust from affecting print quality.

Where Is 608-2RSL/C2GLD Bearing Used?
This bearing pops up in conveyor belt rollers for light packaging lines, where its 34,000 rpm limit keeps things moving efficiently.

The 7mm width fits neatly into printer paper feed mechanisms, reducing friction during high-volume printing jobs. Chrome steel balls ensure consistent performance over time.

Built for Versatility: 608-2SL/C2GLD Bearing
I’ve seen these work well in laboratory centrifuges, handling moderate speeds while maintaining positional accuracy. The -30° to 120°C range covers most lab conditions.

For DIY projects, 608-2RSL/C2GLD Bearing is great for motorised camera sliders – its quiet operation won’t interfere with audio recording. The 11.8g weight won’t overload small rigs.
