Single Row Deep Groove Ball Bearings 6048 M

Single Row Deep Groove Ball Bearings 6048 M

The 6048 M is a single-row deep groove ball bearing with a 240mm bore and 360mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 57,326 lbf and operates smoothly at speeds up to 3000 RPM.

Its open design simplifies maintenance, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a dependable replacement option. Suitable for heavy-duty machinery or industrial equipment where radial load support is essential.

Weighing 19.6kg, it’s built for robust performance. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6048 M
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 240 mm
  • Bore Dia Tolerance -0.022mm to 0
  • Outer Dia 360 mm
  • Outer Dia Tolerance -0.028mm to 0
  • Width 56 mm
  • Width Tolerance -0.3mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 57326 lbf
  • Static Radial Load 70815 lbf
  • Max Speed 3000 rpm
  • Weight 19600 g
  • price（$） 599.157
Single Row Deep Groove Ball Bearings 6048 M dimension drawing
Download DWG Download PDF

Features

Performance Features of 6048 M Bearing

6048 M Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 57,326 lbf, making it suitable for heavy-duty applications.

The stainless steel cage ensures smooth operation by keeping the balls properly aligned.
With a maximum speed of 3,000 rpm, it delivers reliable performance in various conditions.

6048 M Bearing operates efficiently within a temperature range of -30° to 120°C.
Its open design allows for easy maintenance and reduces operational costs.

The P6 tolerance class ensures high precision, making it ideal for demanding tasks.
Its durable construction extends service life, lowering replacement frequency.

Application

Industrial Uses of 6048 M Bearing
The 6048 M Bearing is commonly used in heavy machinery like industrial pumps and large fans, where its radial load capacity handles constant motion efficiently. Its open design simplifies lubrication checks, ideal for maintenance-heavy environments.

In automotive applications, 6048 M Bearing fits well in truck wheel hubs or transmission systems, thanks to its robust chrome steel construction. The P6 tolerance ensures precise alignment, reducing wear over time.

For automation equipment, 6048 M Bearing supports robotic arms and conveyor belts with smooth rotation under moderate speeds. The stainless steel cage adds durability, making it reliable for continuous operation.

Where Is 6048 M Bearing Used?
You’ll find 6048 M Bearing in wind turbine gearboxes, where its large bore size and radial load capacity manage uneven forces effectively. The temperature range also suits outdoor installations.

In printing presses, 6048 M Bearing’s precision reduces vibration for high-quality output. Its metric sizing aligns with European machinery standards, simplifying replacements.
