Single Row Deep Groove Ball Bearings 6030-2Z

Single Row Deep Groove Ball Bearings 6030-2Z

The 6030-2Z is a single-row deep groove ball bearing with a 150mm bore and 225mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 28101 lbf and operates smoothly at speeds up to 3000 RPM.

Its shielded design keeps grease in and dirt out, while the stainless steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 4.38kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6030-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 150 mm
  • Bore Dia Tolerance -0.018mm to 0
  • Outer Dia 225 mm
  • Outer Dia Tolerance -0.020mm to 0
  • Width 35 mm
  • Width Tolerance -0.25mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 28101 lbf
  • Static Radial Load 28101 lbf
  • Max Speed 3000 rpm
  • Weight 4.38 kg
  • price（$） 122.877
Single Row Deep Groove Ball Bearings 6030-2Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 6030-2Z Bearing

6030-2Z Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 28101 lbf.
Its shielded design keeps contaminants out while retaining lubrication for smooth operation.
The stainless steel cage ensures proper ball alignment, reducing friction and wear.
With a maximum speed of 3,000 rpm, it delivers reliable performance in various applications.

Application

Common Applications of 6030-2Z Bearing
The 6030-2Z Bearing is widely used in industrial machinery, such as conveyor systems and large fans, where its shielded design helps keep contaminants out. Its high dynamic radial load capacity makes it suitable for continuous operation in demanding environments.

In automotive applications, 6030-2Z Bearing fits well in wheel hubs and transmission systems, providing reliable performance under radial loads. The grease lubrication ensures smooth operation even at moderate speeds.

For automation equipment, 6030-2Z Bearing’s stainless steel cage and chrome steel construction offer durability in robotic arms and assembly lines. Its P6 tolerance class ensures precision in repetitive motions.

In household appliances like washing machines, 6030-2Z Bearing’s shielded design protects against dust and moisture. The wide temperature range allows it to handle both hot and cold conditions effortlessly.
