Single Row Deep Groove Ball Bearings 6024-2Z/VK298

Single Row Deep Groove Ball Bearings 6024-2Z/VK298

The 6024-2Z/VK298 is a single-row deep groove ball bearing with a 120mm bore and 180mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 19873 lbf and operates smoothly at speeds up to 4800 RPM.

Its shielded design keeps out dust and debris, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Perfect for machinery like pumps or electric motors where radial loads are common.

Weighing 2100g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6024-2Z/VK298
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 19873 lbf
  • Static Radial Load 17985 lbf
  • Max Speed 4800 rpm
  • Weight 2100 g
  • price（$） 94.446
Single Row Deep Groove Ball Bearings 6024-2Z/VK298 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6024-2Z/VK298 Bearing

6024-2Z/VK298 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 19873 lbf, making it suitable for demanding applications.

The shielded design of 6024-2Z/VK298 Bearing protects against contaminants, ensuring smooth operation.
With a maximum speed of 4,800 rpm, it balances durability and efficiency in various conditions.

6024-2Z/VK298 Bearing operates in temperatures from -30°C to 120°C, adapting to different environments.
Its chrome steel cage maintains ball alignment, reducing wear and extending service life.

The ABEC 1 tolerance class ensures reliable performance for standard precision applications.
6024-2Z/VK298 Bearing’s design simplifies installation, saving time and effort.

Application

Common Applications of 6024-2Z/VK298 Bearing
In industrial settings, 6024-2Z/VK298 Bearing is commonly used in machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

Where Is 6024-2Z/VK298 Bearing Used?
You’ll often find 6024-2Z/VK298 Bearing in automotive applications such as wheel hubs and transmissions, thanks to its ability to handle radial loads efficiently. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: 6024-2Z/VK298 Bearing
6024-2Z/VK298 Bearing works well in conveyor systems and agricultural equipment, where its robust design can withstand continuous operation. The ABEC 1 tolerance ensures reliable performance without unnecessary complexity.

Automotive vs Industrial: Applications of 6024-2Z/VK298 Bearing
In automotive uses, 6024-2Z/VK298 Bearing supports smooth rotation in drivetrains, while in industrial gear, it’s trusted for its load capacity. The temperature range of -30° to 120°C adds to its adaptability.

Perfect Fit for Automation: 6024-2Z/VK298 Bearing
6024-2Z/VK298 Bearing is a solid choice for robotic arms and automated assembly lines, where precision and reliability matter. The shielded seals help maintain performance by reducing dust and debris ingress.
