Single Row Deep Groove Ball Bearings 6021-2Z

Single Row Deep Groove Ball Bearings 6021-2Z

The 6021-2Z is a single-row deep groove ball bearing with a 105mm bore and 160mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 17108 lbf and runs smoothly at speeds up to 4300 RPM.

Its shielded design keeps dirt out while the stainless steel cage ensures durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1.67kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6021-2Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 105 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 160 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 26 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 17108 lbf
  • Static Radial Load 14725 lbf
  • Max Speed 4300 rpm
  • Weight 1.67 kg
  • price（$） 48.996
Single Row Deep Groove Ball Bearings 6021-2Z dimension drawing
Download DWG Download PDF

Features

How Does 6021-2Z Bearing Reduce Friction?

6021-2Z Bearing features a single-row deep groove design, optimised for smooth radial load handling.
The chrome steel construction ensures durability while reducing friction during operation.

Its shielded design keeps contaminants out, maintaining consistent performance.
With a dynamic radial load capacity of 17108 lbf, it handles demanding applications reliably.

The grease lubrication extends service life, reducing maintenance needs.
Operating between -30°C to 120°C, it performs well in varied environments.

Application

Industrial Uses of 6021-2Z Bearing
6021-2Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures it can handle radial loads with ease.

Where Is 6021-2Z Bearing Used?
You’ll often find 6021-2Z Bearing in automotive applications such as wheel hubs and alternators, thanks to its reliable performance and grease lubrication. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 6021-2Z Bearing
In automated systems, 6021-2Z Bearing works well in robotic arms and conveyor belts, where smooth operation is key. The stainless steel cage adds durability, making it suitable for high-use environments.

Medical vs Industrial: Where 6021-2Z Bearing Excels
While 6021-2Z Bearing is great for industrial gear, it also fits medical devices like lab equipment, where precision matters. Its temperature range allows it to perform consistently in different settings.

Key Fields for 6021-2Z Bearing
For household appliances like washing machines, 6021-2Z Bearing offers quiet and efficient performance. The shielded seals help extend its lifespan by reducing dust and moisture ingress.
