Single Row Deep Groove Ball Bearings 6016 M/P65HS0VG2211

Single Row Deep Groove Ball Bearings 6016 M/P65HS0VG2211

The 6016 M/P65HS0VG2211 is a single-row deep groove ball bearing with an 80mm bore and 125mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 10701 lbf and operates smoothly at speeds up to 5300 RPM.

Its open design simplifies maintenance, while the machined metal cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 150°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 854g, it balances strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6016 M/P65HS0VG2211
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 3 | ISO P6
  • Radial Clearance Trade No CN
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 125 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Machined metal
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 150 °C
  • Dynamic Radial Load 10701 lbf
  • Static Radial Load 8947 lbf
  • Max Speed 5300 rpm
  • Weight 854 g
  • price（$） 194.796
Single Row Deep Groove Ball Bearings 6016 M/P65HS0VG2211 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6016 M/P65HS0VG2211 Bearing

6016 M/P65HS0VG2211 Bearing is built with chrome steel rings and balls, offering excellent radial load capacity.
Its dynamic radial load reaches 10701 lbf, making it suitable for demanding applications.

The machined metal cage ensures precise ball alignment, reducing friction and wear.
With a maximum speed of 5,300 rpm, it balances performance and durability.

6016 M/P65HS0VG2211 Bearing operates in temperatures from -30° to 150°C, adapting to various environments.
Its open design simplifies maintenance while maintaining reliable operation.

Application

Industrial Uses of 6016 M/P65HS0VG2211 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design efficiently handles radial loads. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6016 M/P65HS0VG2211 Bearing supports components such as alternators and transmission systems. Its ABEC 3 tolerance class provides reliable performance for smooth operation.

For automation equipment, this bearing is ideal for robotic arms and conveyor systems due to its precise radial load capacity. The machined metal cage adds stability during high-speed operations.

In household appliances like washing machines, 6016 M/P65HS0VG2211 Bearing offers quiet and efficient performance. Its wide temperature range makes it suitable for various domestic uses.
