Single Row Deep Groove Ball Bearings 6015

Single Row Deep Groove Ball Bearings 6015

The 6015 is a single-row deep groove ball bearing with a 75mm bore and 115mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 8902 lbf and operates smoothly at speeds up to 5600 RPM.

Its open design simplifies lubrication, while the stainless steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 638g, it strikes a balance between strength and manageability. Compliant with RoHS and REACH standards, it’s a safe choice for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6015
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 115 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 8902 lbf
  • Static Radial Load 7531 lbf
  • Max Speed 5600 rpm
  • Weight 638 g
  • price（$） 17.172
Single Row Deep Groove Ball Bearings 6015 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6015 Bearing

6015 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 8902 lbf.

Its stainless steel cage ensures smooth operation, reducing friction and wear.

The open design allows for easy lubrication, maintaining performance in various conditions.

With a maximum speed of 5,600 rpm, it balances efficiency and durability.

Application

Industrial Uses of 6015 Bearing
The 6015 Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design simplifies lubrication, making maintenance straightforward in demanding environments.

In automotive applications, 6015 Bearing fits well in wheel hubs and transmission systems, thanks to its durable chrome steel construction. The ABEC-1 tolerance provides a good balance of precision and cost-effectiveness for vehicle components.

For automation equipment, 6015 Bearing supports smooth operation in robotic arms and conveyor belts. The stainless steel cage adds longevity, even in high-speed scenarios.

Around the home, 6015 Bearing can be found in appliances like washing machines, where its quiet operation is a plus. The metric sizing ensures compatibility with a variety of European-made devices.

Medical devices like centrifuges benefit from 6015 Bearing’s consistent performance and ease of maintenance. Its temperature range makes it suitable for lab equipment operating under varying conditions.
