Single Row Deep Groove Ball Bearings 6015-ZN

Single Row Deep Groove Ball Bearings 6015-ZN

The 6015-ZN is a single-row deep groove ball bearing with a 75mm bore and 115mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 8902 lbf and operates smoothly at speeds up to 5600 RPM.

Its shielded design keeps dirt out while maintaining smooth rotation, and the chrome steel cage adds durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for applications like electric motors or pumps where radial loads are common.

Weighing 638g, it’s a robust choice for its size. Compliant with RoHS and REACH standards, it’s safe for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6015-ZN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 75 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 115 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 8902 lbf
  • Static Radial Load 7531 lbf
  • Max Speed 5600 rpm
  • Weight 638 g
  • price（$） 31.86
Single Row Deep Groove Ball Bearings 6015-ZN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6015-ZN Bearing

6015-ZN Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 8902 lbf, ensuring reliable performance in various applications.

The shielded design of 6015-ZN Bearing protects against contaminants, extending its service life.
With a maximum speed of 5,600 rpm, it balances durability and efficiency for smooth operation.

6015-ZN Bearing operates in temperatures from -30°C to 120°C, suitable for diverse environments.
Its ABEC 1 tolerance class ensures consistent performance without excessive maintenance.

Application

Industrial Uses of 6015-ZN Bearing
6015-ZN Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability even in demanding environments.

Where Is 6015-ZN Bearing Used?
You’ll often find 6015-ZN Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable radial load handling. Its ABEC 1 tolerance makes it suitable for general-purpose use without compromising performance.

Built for Heavy-Duty Use: 6015-ZN Bearing
6015-ZN Bearing works well in conveyor systems, where its single-row deep groove design supports smooth rotation. The wide temperature range also makes it adaptable to various working conditions.

Automotive vs Industrial: Applications of 6015-ZN Bearing
In automotive settings, 6015-ZN Bearing handles moderate radial loads in components like fans and pulleys. For industrial use, it’s a go-to choice for machinery requiring consistent performance and easy maintenance.
