Single Row Deep Groove Ball Bearings 6012

Single Row Deep Groove Ball Bearings 6012

The 6012 is a single-row deep groove ball bearing with a 60mm bore and 95mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 6609 lbf and operates smoothly at speeds up to 7100 RPM.

Its open design simplifies lubrication, while the stainless steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Perfect for applications like electric motors or pumps where radial loads are common.

Weighing 403g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6012
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 95 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Required
  • REACH Compliant
  • Temperature Range -30° to 110 °C
  • Dynamic Radial Load 6609 lbf
  • Static Radial Load 5216 lbf
  • Max Speed 7100 rpm
  • Weight 403 g
  • price（$） 8.478
Single Row Deep Groove Ball Bearings 6012 dimension drawing
Download DWG Download PDF

Features

How Does 6012 Bearing Reduce Friction?

6012 Bearing features a single-row deep groove design, optimised for smooth radial load handling.
Its chrome steel rings and balls minimise friction, ensuring efficient operation at speeds up to 7,100 rpm.

The stainless steel cage maintains ball alignment, reducing wear and extending service life.
With a dynamic radial load capacity of 6609 lbf, it offers reliable performance in various applications.

6012 Bearing operates within a temperature range of -30° to 110°C, suitable for diverse environments.
Its open design simplifies lubrication, helping maintain consistent performance over time.

Application

Common Applications of 6012 Bearing
The 6012 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures reliable performance. Its open design simplifies lubrication, making maintenance straightforward.

In automotive applications, 6012 Bearing fits well in wheel hubs and transmission systems, providing smooth rotation under varying loads. The chrome steel construction offers durability, even in demanding driving conditions.

For home appliances like washing machines, 6012 Bearing’s compact size and efficiency help reduce noise and vibration. Its ABEC-1 tolerance ensures consistent operation over long periods.

Automation systems benefit from 6012 Bearing’s precision, particularly in conveyor belts and robotic arms. The stainless steel cage adds corrosion resistance, ideal for humid or dusty environments.
