Single Row Deep Groove Ball Bearings 6012-Z

Single Row Deep Groove Ball Bearings 6012-Z

The 6012-Z is a single-row deep groove ball bearing with a 60mm bore and 95mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 6902 lbf and runs smoothly at speeds up to 9500 RPM.

Its shielded design keeps grease in and contaminants out, while the stainless steel cage adds durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where reliable radial load support is needed.

Weighing 0.42kg, it balances strength and compactness. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6012-Z
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 95 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 18 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Lubrication Grease
  • REACH Compliant
  • Temperature Range -30° to 120 °C
  • Dynamic Radial Load 6902 lbf
  • Static Radial Load 5216 lbf
  • Max Speed 9500 rpm
  • Weight 0.42 kg
  • price（$） 9.441
Single Row Deep Groove Ball Bearings 6012-Z dimension drawing
Download DWG Download PDF

Features

How Does 6012-Z Bearing Reduce Friction?

6012-Z Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
The shielded seal helps retain lubrication while keeping contaminants out, enhancing performance.

Its chrome steel construction ensures durability and consistent operation under various conditions.
With a dynamic radial load capacity of 6902 lbf, it handles demanding applications efficiently.

The grease lubrication reduces friction, allowing speeds up to 9,500 rpm without excessive wear.
This makes 6012-Z Bearing a reliable choice for both industrial and precision machinery.

Application

Industrial Uses of 6012-Z Bearing
6012-Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures it can handle radial loads efficiently in demanding environments.

What Makes 6012-Z Bearing a Preferred Choice?
In automotive applications, 6012-Z Bearing fits well in components such as alternators and wheel hubs, providing smooth rotation. Its P6 tolerance class offers precision, making it reliable for long-term use.

Perfect Fit for Automation: 6012-Z Bearing
For automated systems, 6012-Z Bearing works effectively in robotic arms and conveyor belts. The grease lubrication reduces friction, ensuring consistent performance even at higher speeds.

Medical vs Industrial: Where 6012-Z Bearing Excels
In medical devices, 6012-Z Bearing is suitable for low-noise equipment like dental drills. Its stainless steel cage adds durability, while the shielded seals maintain cleanliness in sensitive environments.

Where to Use 6012-Z Bearing
In household appliances like washing machines, 6012-Z Bearing supports smooth operation with minimal maintenance. The metric sizing makes it easy to replace in various European and Asian models.
