Single Row Deep Groove Ball Bearings 6007-2Z/WT

Single Row Deep Groove Ball Bearings 6007-2Z/WT

The 6007-2Z/WT is a single-row deep groove ball bearing with a 35mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 3574 lbf and spins smoothly at speeds up to 11000 RPM.

Its shielded design keeps dirt out while maintaining smooth operation, and the chrome steel cage adds durability. The bearing performs well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s ideal for applications like electric motors or small machinery where reliable radial load support is needed.

Weighing just 155g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6007-2Z/WT
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 14 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 2316 lbf
  • Max Speed 11000 rpm
  • Weight 155 g
Single Row Deep Groove Ball Bearings 6007-2Z/WT dimension drawing
Download DWG Download PDF

Features

Performance Features of 6007-2Z/WT Bearing

6007-2Z/WT Bearing is designed for radial loads, with a dynamic radial load capacity of 3574 lbf.
Its shielded construction protects against contaminants, ensuring smooth operation in various environments.
The chrome steel rings and balls provide durability, while the ABEC 1 tolerance class ensures reliable performance.
With a maximum speed of 11,000 rpm, it is suitable for high-speed applications.

Application

Common Applications of 6007-2Z/WT Bearing
6007-2Z/WT Bearing is widely used in industrial equipment like electric motors and pumps, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 6007-2Z/WT Bearing fits well in components such as alternators and water pumps, providing reliable radial load support. Its metric sizing makes it a versatile choice for various vehicle models.

For home appliances, 6007-2Z/WT Bearing works efficiently in items like washing machines and fans, offering smooth operation. The ABEC 1 tolerance ensures consistent performance for everyday use.

What Makes 6007-2Z/WT Bearing a Preferred Choice?
6007-2Z/WT Bearing is a go-to option for small machinery due to its balanced load capacity and moderate speed handling. The shielded seals add extra protection without compromising performance.

In automation systems, 6007-2Z/WT Bearing supports robotic arms and conveyor belts with its reliable radial load capacity. The chrome steel cage enhances longevity even in high-use scenarios.
