Single Row Deep Groove Ball Bearings 6006/W64

Single Row Deep Groove Ball Bearings 6006/W64

The 6006/W64 is a single-row deep groove ball bearing with a 30mm bore and 55mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2967 lbf and spins efficiently at speeds up to 13000 RPM.

Its open design and solid oil lubrication ensure smooth operation with minimal maintenance. The chrome steel cage adds durability, making it suitable for long-term use in various conditions.

This bearing works well in temperatures ranging from -30°C to 120°C, fitting applications like electric motors or small machinery. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Weighing just 116g, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s a safe and practical choice for radial load applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6006/W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 55 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 13 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2967 lbf
  • Static Radial Load 1855 lbf
  • Max Speed 13000 rpm
  • Weight 116 g
  • price（$） 9.369
Single Row Deep Groove Ball Bearings 6006/W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6006/W64 Bearing

6006/W64 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 2967 lbf, making it suitable for various applications.
The solid oil lubrication ensures consistent performance, reducing the need for frequent maintenance.
With a maximum speed of 13,000 rpm, it delivers both durability and efficiency.

How Is 6006/W64 Bearing Engineered for Reliability?

6006/W64 Bearing features a single row deep groove design, optimised for smooth radial load handling.
The chrome steel construction enhances durability, even in demanding conditions.
Its ABEC 1 tolerance ensures reliable performance, while the solid oil lubrication extends service life.
Operating within a temperature range of -30°C to 120°C, it adapts to various environments.

Designed for Durability: 6006/W64 Bearing

6006/W64 Bearing’s chrome steel cage keeps the balls aligned, minimising wear and tear.
The solid oil lubrication reduces friction, ensuring quiet and efficient operation.
With a static radial load capacity of 1855 lbf, it handles moderate loads with ease.
Its compact size (30 mm×55 mm×13 mm) makes it ideal for space-constrained applications.

Application

Common Applications of 6006/W64 Bearing
6006/W64 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures reliable performance. The solid oil lubrication extends service life, reducing maintenance needs in continuous operation.

In automotive applications, 6006/W64 Bearing fits well in alternators and wheel hubs, providing smooth rotation under varying speeds. Its chrome steel construction offers durability, even in demanding driving conditions.

For home appliances like washing machines, 6006/W64 Bearing’s quiet operation and low friction make it ideal. The open design allows for easy cleaning, ensuring longevity in everyday use.

Automation systems benefit from 6006/W64 Bearing’s precision, particularly in conveyor belts and robotic arms. The metric sizing ensures compatibility with a range of equipment, simplifying replacements.
