Single Row Deep Groove Ball Bearings 6005J

Single Row Deep Groove Ball Bearings 6005J

The 6005J is a single-row deep groove ball bearing with a 25mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2271 lbf and spins smoothly at speeds up to 15000 RPM.

Its open design simplifies maintenance, while the chrome steel cage ensures durability. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for applications like electric motors or small machinery where radial loads are common.

Weighing just 80g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6005J
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2271 lbf
  • Static Radial Load 1315 lbf
  • Max Speed 15000 rpm
  • Weight 80 g
  • price（$） 4.347
Single Row Deep Groove Ball Bearings 6005J dimension drawing
Download DWG Download PDF

Features

Performance Features of 6005J Bearing

6005J Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 2271 lbf.
Its single-row deep groove design ensures smooth operation and efficient load distribution.
The open seal type allows for easy maintenance and lubrication adjustments.
With a maximum speed of 15,000 rpm, it delivers reliable performance in various applications.

Application

Industrial Uses of 6005J Bearing
The 6005J Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures reliable performance. Its open design simplifies lubrication and maintenance, making it suitable for continuous operation.

What Makes 6005J Bearing a Preferred Choice?
In automotive applications, 6005J Bearing fits well in components such as alternators and wheel hubs, thanks to its balanced load handling. The chrome steel construction provides durability under varying temperatures and speeds.

Built for Versatility: 6005J Bearing
For household appliances like washing machines, 6005J Bearing offers smooth and quiet operation. Its compact size and lightweight design make it ideal for space-constrained applications.

Automotive vs Industrial: Applications of 6005J Bearing
While 6005J Bearing excels in car transmissions, it also performs well in conveyor systems. The ABEC 1 tolerance ensures consistent quality across different uses.

Perfect Fit for Automation: 6005J Bearing
In robotic arms and 3D printers, 6005J Bearing provides precise movement with minimal friction. The chrome steel cage enhances longevity even in high-speed scenarios.
