Single Row Deep Groove Ball Bearings 6005J/C3

Single Row Deep Groove Ball Bearings 6005J/C3

The 6005J/C3 is a single-row deep groove ball bearing with a 25mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 2271 lbf and operates smoothly at speeds up to 15000 RPM.

With its open design and C3 radial clearance, it offers flexibility in various conditions, while the chrome steel cage enhances durability. It performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or small machinery where radial loads are common.

Weighing just 80g, it’s lightweight yet robust. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6005J/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2271 lbf
  • Static Radial Load 1315 lbf
  • Max Speed 15000 rpm
  • Weight 80 g
  • price（$） 3.672
Single Row Deep Groove Ball Bearings 6005J/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6005J/C3 Bearing

6005J/C3 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 2271 lbf.
Its single-row deep groove design ensures smooth rotation and efficient load distribution.
With a maximum speed of 15,000 rpm, it suits high-speed applications while maintaining stability.
The C3 radial clearance provides flexibility in various operating conditions.

Application

Common Applications of 6005J/C3 Bearing
The 6005J/C3 Bearing is widely used in industrial equipment like electric motors and pumps, where its radial load capacity ensures reliable performance. Its open design and C3 clearance make it suitable for applications with thermal expansion needs.

How Does 6005J/C3 Bearing Improve Performance?
In automotive systems, 6005J/C3 Bearing enhances efficiency in components such as alternators and water pumps. The chrome steel construction provides durability, while the metric sizing ensures compatibility with various vehicle designs.

Ideal for Precision: 6005J/C3 Bearing
For automation and robotics, 6005J/C3 Bearing offers smooth operation in precision devices like robotic arms. Its high-speed capability and consistent performance make it a dependable choice for repetitive tasks.

Automotive vs Industrial: Applications of 6005J/C3 Bearing
In automotive uses, 6005J/C3 Bearing supports lightweight components, while in industrial settings, it handles heavier radial loads. The bearing’s versatility makes it a go-to solution across different sectors.

Where to Use 6005J/C3 Bearing
You’ll often find 6005J/C3 Bearing in household appliances like washing machines, where its quiet operation and durability are key. The wide temperature range also ensures reliability in various environments.
