Single Row Deep Groove Ball Bearings 6005 TN9

Single Row Deep Groove Ball Bearings 6005 TN9

The 6005 TN9 is a single-row deep groove ball bearing with a 25mm bore and 47mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 2271 lbf and operates smoothly at speeds up to 15,000 RPM.

Its open design allows for easy lubrication, while the nylon cage reduces friction and noise. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or small machinery where radial loads are common.

Weighing just 80g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6005 TN9
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2271 lbf
  • Static Radial Load 1315 lbf
  • Max Speed 15000 rpm
  • Weight 80 g
Single Row Deep Groove Ball Bearings 6005 TN9 dimension drawing
Download DWG Download PDF

Features

How Does 6005 TN9 Bearing Reduce Friction?

6005 TN9 Bearing features a deep groove design, optimised for smooth radial load distribution.
The chrome steel construction ensures durability while maintaining low friction during operation.

Its nylon cage minimises contact between balls, reducing wear and enhancing efficiency.
With a maximum speed of 15,000 rpm, it delivers reliable performance in various applications.

The open seal design allows for easy maintenance and adaptability to different environments.
6005 TN9 Bearing operates efficiently within a temperature range of -30°C to 120°C.

Application

Common Applications of 6005 TN9 Bearing
6005 TN9 Bearing is widely used in industrial equipment like conveyor belts and small electric motors, where its radial load capacity and smooth operation are beneficial. The open design allows for easy lubrication, extending its service life in dusty environments.

Where Is 6005 TN9 Bearing Used?
In automotive applications, 6005 TN9 Bearing fits well in alternators and water pumps, thanks to its reliable performance and compatibility with standard metric sizes. The nylon cage reduces noise, making it suitable for quieter vehicle systems.

Ideal for Precision: 6005 TN9 Bearing
For medical devices such as dental drills and lab equipment, 6005 TN9 Bearing offers consistent performance due to its chrome steel construction. The ABEC 1 tolerance ensures adequate precision for most medical applications.

Automotive vs Industrial: Applications of 6005 TN9 Bearing
While 6005 TN9 Bearing excels in automotive components like fans and pulleys, it also performs well in industrial settings such as small gearboxes. Its versatility makes it a go-to choice for various radial load needs.

Practical Applications of 6005 TN9 Bearing
In home appliances like washing machines and power tools, 6005 TN9 Bearing provides durability and quiet operation. The wide temperature range ensures reliability even under varying household conditions.
