Single Row Deep Groove Ball Bearings 6004 TN9/C4

Single Row Deep Groove Ball Bearings 6004 TN9/C4

The 6004 TN9/C4 is a single-row deep groove ball bearing with a 20mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2113 lbf and spins smoothly at speeds up to 17000 RPM.

Its open design and nylon cage reduce friction, making it efficient for high-speed applications. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Perfect for use in electric motors or small machinery where radial loads are common.

Weighing just 69g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6004 TN9/C4
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C4
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2113 lbf
  • Static Radial Load 1135 lbf
  • Max Speed 17000 rpm
  • Weight 69 g
Single Row Deep Groove Ball Bearings 6004 TN9/C4 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6004 TN9/C4 Bearing

6004 TN9/C4 Bearing is built with chrome steel rings and balls, offering reliable radial load support.

Its dynamic radial load capacity of 2113 lbf ensures steady performance in various applications.

The nylon cage helps reduce friction and noise, making it suitable for quieter operations.

With a maximum speed of 17,000 rpm, it balances speed and durability effectively.

Application

Common Applications of 6004 TN9/C4 Bearing
6004 TN9/C4 Bearing is widely used in industrial machinery, such as electric motors and pumps, where its radial load capacity ensures smooth operation. The open design and nylon cage make it suitable for moderate-speed applications.

In automotive systems, 6004 TN9/C4 Bearing fits well in components like alternators and water pumps, offering reliable performance. Its metric sizing and ABEC 1 tolerance make it a versatile choice for various vehicle models.

For home appliances, 6004 TN9/C4 Bearing works efficiently in devices like washing machines and fans. The chrome steel construction provides durability, while the C4 clearance accommodates thermal expansion.

How Does 6004 TN9/C4 Bearing Support High-Speed Operations?
6004 TN9/C4 Bearing handles high-speed rotations up to 17,000 rpm, making it ideal for applications like power tools and small machinery. The nylon cage reduces friction, enhancing efficiency.

Its balanced design ensures minimal vibration, which is crucial for precision equipment. The wide temperature range also allows it to perform reliably in varying conditions.
