Single Row Deep Groove Ball Bearings 6004 JEM

Single Row Deep Groove Ball Bearings 6004 JEM

The 6004 JEM is a single-row deep groove ball bearing with a 20mm bore and 42mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 2113 lbf and spins smoothly at speeds up to 17,000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability. The bearing operates well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Perfect for applications like electric motors or small machinery where radial loads are common.

Weighing just 69g, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6004 JEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 2113 lbf
  • Static Radial Load 1135 lbf
  • Max Speed 17000 rpm
  • Weight 69 g
  • price（$） 4.626
Single Row Deep Groove Ball Bearings 6004 JEM dimension drawing
Download DWG Download PDF

Features

Performance Features of 6004 JEM Bearing

6004 JEM Bearing is built with chrome steel rings and balls, offering strong radial load support.
Its dynamic radial load capacity reaches 2113 lbf, making it suitable for various applications.
The single-row deep groove design ensures smooth operation and efficient load distribution.
With a maximum speed of 17,000 rpm, it balances performance and durability.

Why Choose 6004 JEM Bearing for Precision Tasks?

6004 JEM Bearing features a precise ABEC 1 tolerance class, ensuring reliable performance in radial applications.
The chrome steel construction resists wear, extending the bearing’s service life.
Its open design allows for easy lubrication, reducing maintenance needs.
Operating within a temperature range of -30°C to 120°C, it adapts to various environments.

Designed for Durability: 6004 JEM Bearing

6004 JEM Bearing’s chrome steel cage keeps the balls aligned, minimising friction and wear.
The deep groove design enhances load capacity while maintaining smooth rotation.
With a static radial load of 1135 lbf, it provides reliable support in demanding conditions.
Its lightweight design at 69 grams ensures easy handling without compromising strength.

Steel vs Ceramic Bearings: Strengths of 6004 JEM Bearing

6004 JEM Bearing uses chrome steel for all components, offering a cost-effective yet durable solution.
The material choice provides excellent resistance to wear and fatigue in radial applications.
Unlike ceramic options, it maintains performance across a wide temperature range.
Its 42 mm outer diameter and 12 mm width make it versatile for various machinery needs.

Application

Common Applications of 6004 JEM Bearing
6004 JEM Bearing is widely used in industrial equipment like conveyor systems and small machinery, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, making it suitable for high-speed environments.

In automotive applications, 6004 JEM Bearing fits well in components such as alternators and small electric motors. Its chrome steel construction provides durability, even under continuous use.

For home appliances, 6004 JEM Bearing is a reliable choice for items like washing machines and fans. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Automation systems benefit from 6004 JEM Bearing in robotic arms and small actuators. Its lightweight design and high-speed capability make it ideal for precision movements.

Medical devices like small pumps and lab equipment often use 6004 JEM Bearing for its quiet operation and reliability. The temperature range also suits various clinical environments.
