Single Row Deep Groove Ball Bearings 6001-RSH/C3

Single Row Deep Groove Ball Bearings 6001-RSH/C3

The 6001-RSH/C3 is a compact single row deep groove ball bearing, measuring 12mm by 28mm by 8mm. Made from durable chrome steel, it handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its sealed design keeps out dust and dirt, reducing maintenance needs. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 120°C.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for small motors, power tools, or appliances where space is limited.

Weighing just 22g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001-RSH/C3
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
  • price（$） 4.356
Single Row Deep Groove Ball Bearings 6001-RSH/C3 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6001-RSH/C3 Bearing

6001-RSH/C3 Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 1147 lbf.
Its sealed design protects against contaminants, making it suitable for various environments.

The C3 radial clearance ensures smooth operation even at high speeds, reaching up to 27,000 rpm.
With a temperature range of -30°C to 120°C, it performs reliably in diverse conditions.

6001-RSH/C3 Bearing’s compact size (12 mm×28 mm×8 mm) makes it ideal for space-constrained applications.
The chrome steel cage enhances durability, reducing wear over time.

Application

Common Applications of 6001-RSH/C3 Bearing
In industrial settings, 6001-RSH/C3 Bearing is widely used in electric motors and pumps due to its sealed design, which helps keep contaminants out. Its C3 clearance also accommodates thermal expansion, making it suitable for varied operating conditions.

Where Is 6001-RSH/C3 Bearing Used?
You’ll often find 6001-RSH/C3 Bearing in automotive applications like alternators and small gearboxes, where its radial load capacity and sealed construction ensure reliable performance. The chrome steel materials add durability for long-term use.

Built for Heavy-Duty Use: 6001-RSH/C3 Bearing
6001-RSH/C3 Bearing works well in conveyor systems and agricultural machinery, handling moderate radial loads with ease. The sealed design reduces maintenance needs, even in dusty or humid environments.

Light-Duty vs Heavy-Duty: Best Uses for 6001-RSH/C3 Bearing
For light-duty tasks, 6001-RSH/C3 Bearing fits well in household appliances like washing machines, offering quiet operation. In heavier applications, it supports small industrial fans and power tools reliably.

Perfect Fit for Automation: 6001-RSH/C3 Bearing
6001-RSH/C3 Bearing is a go-to choice for robotic arms and small automation systems, thanks to its precise movement and sealed protection. The metric sizing ensures compatibility with many standard designs.
