Single Row Deep Groove Ball Bearings 6001-RS1/VK016

The 6001-RS1/VK016 is a compact single row deep groove ball bearing, measuring 12mm by 28mm by 8mm. Made from durable chrome steel, it handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its sealed design keeps out dust and dirt, making it low-maintenance for long-term use. The bearing operates well in temperatures from -30°C to 120°C, suitable for various environments.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for small motors, pumps, or appliances where space is limited but performance is key.

Weighing just 22g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6001-RS1/VK016
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Sealed
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Bore Dia 12 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 28 mm
Outer Dia Tolerance -0.009mm to 0
Width 8 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Chrome Steel
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 1147 lbf
Static Radial Load 54 lbf
Max Speed 27000 rpm
Weight 22 g

Single Row Deep Groove Ball Bearings 6001-RS1/VK016 dimension drawing

Download DWG Download PDF

Features

Performance Features of 6001-RS1/VK016 Bearing

6001-RS1/VK016 Bearing is built with chrome steel rings and balls, offering reliable radial load support.
Its sealed design protects against dust and moisture, ensuring smooth operation in various environments.

The ABEC 1 tolerance class ensures consistent performance, suitable for general applications.
With a dynamic radial load capacity of 1147 lbf, it handles moderate loads efficiently.

6001-RS1/VK016 Bearing operates within a temperature range of -30°C to 120°C, adapting to diverse conditions.
Its maximum speed of 27,000 rpm makes it ideal for high-speed applications.

The compact size of 12 mm×28 mm×8 mm allows easy integration into space-constrained designs.
Weighing just 22 g, it adds minimal weight while maintaining durability.

Application

Common Applications of 6001-RS1/VK016 Bearing
6001-RS1/VK016 Bearing is widely used in small electric motors, such as those found in household appliances and power tools. Its sealed design helps keep out dust and moisture, ensuring longer service life in everyday conditions.

Where Is 6001-RS1/VK016 Bearing Used?
You’ll often spot 6001-RS1/VK016 Bearing in conveyor systems, where its radial load capacity keeps things running smoothly. The chrome steel construction also makes it a reliable choice for light industrial machinery.

Built for Versatility: 6001-RS1/VK016 Bearing
6001-RS1/VK016 Bearing works well in automotive applications like alternators and small gearboxes. Its compact size and sealed design make it suitable for tight spaces where maintenance access is limited.

Automotive vs Industrial: Applications of 6001-RS1/VK016 Bearing
In cars, 6001-RS1/VK016 Bearing handles radial loads in components like water pumps. For industrial uses, it’s a go-to for small machinery where consistent performance matters.
