Single Row Deep Groove Ball Bearings 6001-2Z/C3GJN

Single Row Deep Groove Ball Bearings 6001-2Z/C3GJN

The 6001-2Z/C3GJN is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 8mm. Made from durable chrome steel, it handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its shielded design keeps dirt out while the C3 radial clearance ensures reliable performance under varying temperatures. The bearing operates well in conditions ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where space is limited.

Weighing just 22g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001-2Z/C3GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
  • price（$） 2.574
Single Row Deep Groove Ball Bearings 6001-2Z/C3GJN dimension drawing
Download DWG Download PDF

Features

How Does 6001-2Z/C3GJN Bearing Reduce Friction?

6001-2Z/C3GJN Bearing features a single-row deep groove design, optimised for smooth radial load distribution.
Its shielded construction helps keep contaminants out while maintaining low friction.
The chrome steel rings and balls ensure durability, even at high speeds up to 27,000 rpm.
With a C3 radial clearance, it accommodates thermal expansion without compromising performance.

Application

Industrial Uses of 6001-2Z/C3GJN Bearing
6001-2Z/C3GJN Bearing is commonly used in small electric motors and pumps, where its shielded design helps keep contaminants out. The C3 radial clearance ensures smooth operation even under varying thermal conditions.

In automotive applications, 6001-2Z/C3GJN Bearing fits well in alternators and cooling fans, thanks to its balanced radial load capacity. The chrome steel construction provides durability in these high-use components.

For household appliances like washing machines, 6001-2Z/C3GJN Bearing offers reliable performance with minimal maintenance. Its compact size and metric dimensions make it easy to integrate into various designs.

Where Is 6001-2Z/C3GJN Bearing Used?
You’ll often find 6001-2Z/C3GJN Bearing in office equipment such as printers and scanners, where quiet operation is key. The shielded seals help prolong bearing life by reducing dust ingress.

In light industrial machinery, 6001-2Z/C3GJN Bearing handles moderate radial loads with ease. Its ABEC 1 tolerance class strikes a good balance between precision and cost-effectiveness.

Built for Versatility: 6001-2Z/C3GJN Bearing
6001-2Z/C3GJN Bearing works well in small gearboxes and power tools, where space is limited but performance matters. The chrome steel cage adds extra strength for these demanding applications.

Its temperature range of -30° to 120°C makes 6001-2Z/C3GJN Bearing suitable for various environments. Whether it’s a food processing machine or a workshop drill, this bearing adapts easily.

Light-Duty vs Heavy-Duty: Best Uses for 6001-2Z/C3GJN Bearing
For light-duty tasks like ceiling fans or small conveyors, 6001-2Z/C3GJN Bearing provides reliable rotation with minimal friction. The 28mm outer diameter fits standard housings perfectly.

In more demanding scenarios like agricultural equipment, 6001-2Z/C3GJN Bearing’s C3 clearance helps accommodate slight misalignments. It’s a practical choice where conditions aren’t always ideal.
