Single Row Deep Groove Ball Bearings 6001-2RSH/VL256W64F

Single Row Deep Groove Ball Bearings 6001-2RSH/VL256W64F

The 6001-2RSH/VL256W64F is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 8mm. Made from chrome steel, it handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Its sealed design keeps dirt out and solid oil lubrication ensures long service life without frequent maintenance. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making replacements straightforward. Ideal for small motors, fans, or appliances where space is limited but performance matters.

Weighing just 22g, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use in various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001-2RSH/VL256W64F
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
Single Row Deep Groove Ball Bearings 6001-2RSH/VL256W64F dimension drawing
Download DWG Download PDF

Features

Why Choose 6001-2RSH/VL256W64F Bearing for Precision Tasks?

6001-2RSH/VL256W64F Bearing features a sealed design with solid oil lubrication, ensuring smooth operation in radial load applications.
Its chrome steel construction provides durability and resistance to wear, making it suitable for long-term use.
With a dynamic radial load capacity of 1147 lbf, it handles demanding conditions efficiently.
The bearing operates within a temperature range of -30°C to 120°C, offering versatility in various environments.

Application

Common Applications of 6001-2RSH/VL256W64F Bearing
In industrial settings, 6001-2RSH/VL256W64F Bearing is commonly used in small motors and pumps, where its sealed design keeps contaminants out. The solid oil lubrication ensures long service life even in dusty environments.

How Does 6001-2RSH/VL256W64F Bearing Improve Performance?
For automotive applications like alternators and cooling fans, 6001-2RSH/VL256W64F Bearing offers smooth rotation and low noise. Its chrome steel construction provides reliable performance under radial loads.

Ideal for Precision: 6001-2RSH/VL256W64F Bearing
In medical devices such as dental handpieces, 6001-2RSH/VL256W64F Bearing delivers consistent accuracy. The ABEC 1 tolerance ensures dependable operation in sensitive equipment.

Automotive vs Industrial: Applications of 6001-2RSH/VL256W64F Bearing
While 6001-2RSH/VL256W64F Bearing excels in car components like wiper motors, it’s equally effective in conveyor systems. The metric sizing makes it versatile for various machinery.

Perfect Fit for Automation: 6001-2RSH/VL256W64F Bearing
In robotic arms and 3D printers, 6001-2RSH/VL256W64F Bearing provides quiet and efficient movement. The sealed design prevents lubricant leakage in continuous operation.
