Single Row Deep Groove Ball Bearings 6001-2RS1 /C3GJN

Single Row Deep Groove Ball Bearings 6001-2RS1 /C3GJN

The 6001-2RS1 is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 8mm, crafted from sturdy chrome steel. It handles radial loads up to 1147 lbf and spins smoothly at speeds up to 27,000 RPM.

Sealed on both sides, it keeps dirt out and grease in, making it low-maintenance. The C3 radial clearance ensures reliable performance under varying temperatures, from -30°C to 120°C.

Its chrome steel cage adds durability, while the ABEC 1 tolerance offers consistent operation. This model is interchangeable with SKF bearings for easy replacements.

Ideal for small motors, pumps, or appliances where space is tight but reliability is key. Compliant with RoHS and REACH standards for safe use. Weighing just 22g, it’s lightweight yet robust.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6001-2RS1 /C3GJN
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 28 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 8 mm
  • Width Tolerance -0.120mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1147 lbf
  • Static Radial Load 54 lbf
  • Max Speed 27000 rpm
  • Weight 22 g
  • price（$） 3.852
Single Row Deep Groove Ball Bearings 6001-2RS1 /C3GJN dimension drawing
Download DWG Download PDF

Features

How Does 6001-2RS1 /C3GJN Bearing Reduce Friction?

6001-2RS1 /C3GJN Bearing features a sealed design, keeping contaminants out and lubrication in for smoother operation.
Its chrome steel construction ensures durability while reducing friction during high-speed rotations.
The C3 radial clearance allows for thermal expansion, maintaining performance in varying temperatures.
With a maximum speed of 27,000 rpm, it delivers reliable efficiency in radial load applications.

Application

Common Applications of 6001-2RS1 /C3GJN Bearing
In industrial settings, 6001-2RS1 /C3GJN Bearing is commonly used in electric motors and pumps, where its sealed design helps keep contaminants out. The C3 clearance ensures reliable performance even under varying thermal conditions.

Where Is 6001-2RS1 /C3GJN Bearing Used?
You’ll often find 6001-2RS1 /C3GJN Bearing in automotive applications like alternators and small gearboxes. Its chrome steel construction offers durability, while the sealed design reduces maintenance needs.

Ideal for Precision: 6001-2RS1 /C3GJN Bearing
For medical devices such as dental drills or lab equipment, 6001-2RS1 /C3GJN Bearing provides smooth, quiet operation. The ABEC 1 tolerance ensures consistent performance in sensitive environments.

Automotive vs Industrial: Applications of 6001-2RS1 /C3GJN Bearing
In cars, 6001-2RS1 /C3GJN Bearing handles radial loads in components like fans and small transmissions. In factories, it’s a go-to for conveyor rollers and light machinery due to its balanced load capacity.

Practical Applications of 6001-2RS1 /C3GJN Bearing
Household appliances like washing machines and power tools benefit from 6001-2RS1 /C3GJN Bearing’s sealed design, which prolongs lifespan by shielding against dust and moisture. Its compact size fits neatly into tight spaces.
