Single Row Deep Groove Ball Bearings 6000-2ZTN9/C3HT

The 6000-2ZTN9/C3HT is a compact single-row deep groove ball bearing, measuring 10mm by 26mm by 8mm, crafted from durable chrome steel. It handles radial loads up to 1023 lbf and spins smoothly at speeds up to 31,000 RPM.

Its shielded design keeps dust out while the nylon cage reduces friction for quieter operation. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for small motors or appliances where space is limited.

Weighing just 19g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 6000-2ZTN9/C3HT
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Shielded
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No C3
Bore Dia 10 mm
Bore Dia Tolerance -0.008mm to 0
Outer Dia 26 mm
Outer Dia Tolerance -0.009mm to 0
Width 8 mm
Width Tolerance -0.120mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Nylon
ROHS Compliant
REACH Compliant
Temperature Range -30°to 120 °C
Dynamic Radial Load 1023 lbf
Static Radial Load 438 lbf
Max Speed 31000 rpm
Weight 19 g

Single Row Deep Groove Ball Bearings 6000-2ZTN9/C3HT dimension drawing

Download DWG Download PDF

Features

Performance Features of 6000-2ZTN9/C3HT Bearing

6000-2ZTN9/C3HT Bearing is designed for radial loads, with a dynamic radial load capacity of 1023 lbf.
Its chrome steel construction ensures durability and resistance to wear in various applications.

The shielded design of 6000-2ZTN9/C3HT Bearing protects against contaminants, extending its service life.
With a maximum speed of 31,000 rpm, it offers reliable performance for high-speed operations.

6000-2ZTN9/C3HT Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its nylon cage reduces friction and noise, making it suitable for precision instruments.

Application

Common Applications of 6000-2ZTN9/C3HT Bearing
This shielded deep groove ball bearing is widely used in small electric motors, thanks to its compact 10mm bore and reliable radial load capacity. The nylon cage helps reduce noise, making it ideal for household appliances like fans or blenders.

How Does 6000-2ZTN9/C3HT Bearing Improve Performance?
In conveyor systems, 6000-2ZTN9/C3HT Bearing handles moderate speeds smoothly while its C3 clearance accommodates thermal expansion. The chrome steel construction ensures durability in dusty workshop environments.

Perfect Fit for Automation: 6000-2ZTN9/C3HT Bearing
You’ll often spot 6000-2ZTN9/C3HT Bearing in 3D printer components where its 8mm width saves space without compromising performance. The shielded design keeps contaminants out during continuous operation.

Industrial vs Consumer Uses: 6000-2ZTN9/C3HT Bearing
While 6000-2ZTN9/C3HT Bearing works well in power tools, it’s equally effective in textile machinery spindles. Its 31,000 rpm limit covers most light industrial speed requirements comfortably.
