Single Row Deep Groove Ball Bearings 310MFF3-H501

Single Row Deep Groove Ball Bearings 310MFF3-H501

The 310MFF3-H501 is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14478 lbf and operates smoothly at speeds up to 7000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like electric motors or pumps where radial loads are predominant.

Weighing 1.15kg, it balances strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 310MFF3-H501
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 14478 lbf
  • Static Radial Load 11690 lbf
  • Max Speed 7000 rpm
  • Weight 1.15 kg
  • price（$） 15.966
Single Row Deep Groove Ball Bearings 310MFF3-H501 dimension drawing
Download DWG Download PDF

Features

Performance Features of 310MFF3-H501 Bearing

310MFF3-H501 Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 14,478 lbf, making it suitable for demanding industrial applications.

The single-row deep groove design ensures smooth operation and reduces friction during use.
With a maximum speed of 7,000 rpm, it balances performance and durability in various conditions.

310MFF3-H501 Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its open design allows for easy maintenance and lubrication, ensuring long service life.

The precision-engineered cage keeps the balls aligned, minimising wear and noise.
This makes 310MFF3-H501 Bearing a reliable choice for machinery requiring consistent performance.

Application

Industrial Uses of 310MFF3-H501 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The open seal type allows for easy lubrication, extending service life in demanding conditions.

What Makes 310MFF3-H501 Bearing a Preferred Choice?
In automotive applications, it supports components such as alternators and water pumps, thanks to its balanced load capacity. The chrome steel construction ensures durability even under continuous use.

Built for Heavy-Duty Use: 310MFF3-H501 Bearing
For automation systems, this bearing fits well in conveyor belts and robotic arms, providing smooth rotation. Its ABEC 1 tolerance offers reliable performance without needing high precision adjustments.

Light-Duty vs Heavy-Duty: Best Uses for 310MFF3-H501 Bearing
In household appliances like washing machines, 310MFF3-H501 Bearing ensures quiet operation and longevity. For industrial gearboxes, it handles higher loads while maintaining stability.
