Single Row Deep Groove Ball Bearings 305SZZST-W64

Single Row Deep Groove Ball Bearings 305SZZST-W64

The 305SZZST-W64 is a single-row deep groove ball bearing with a 25mm bore and 62mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 5148 lbf and operates smoothly at speeds up to 13,000 RPM.

Its shielded design keeps dirt out while the solid oil lubrication ensures long service life without frequent maintenance. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for electric motors or pumps where radial loads are common.

Weighing 0.24kg, it’s a compact yet durable choice for various industrial applications. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 305SZZST-W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 5148 lbf
  • Static Radial Load 3507 lbf
  • Max Speed 13000 rpm
  • Weight 0.24 kg
  • price（$） 42.651
Single Row Deep Groove Ball Bearings 305SZZST-W64 dimension drawing
Download DWG Download PDF

Features

Performance Features of 305SZZST-W64 Bearing

305SZZST-W64 Bearing features a shielded design, protecting it from dust and debris while maintaining smooth operation.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

The solid oil lubrication reduces maintenance needs, providing long-lasting performance.
With a dynamic radial load capacity of 5148 lbf, it handles demanding conditions reliably.

305SZZST-W64 Bearing operates efficiently at speeds up to 13,000 rpm, balancing speed and durability.
Its temperature range of -30°C to 120°C makes it suitable for various environments.

Application

Industrial Uses of 305SZZST-W64 Bearing
305SZZST-W64 Bearing is commonly used in conveyor systems and electric motors, where its shielded design protects against dust and debris. The solid oil lubrication ensures long service life with minimal maintenance.

In automotive applications, 305SZZST-W64 Bearing fits well in alternators and water pumps, handling radial loads efficiently. Its chrome steel construction offers good resistance to wear in high-temperature environments.

For home appliances like washing machines, 305SZZST-W64 Bearing provides quiet and smooth operation. The ABEC 1 tolerance makes it reliable for everyday use without needing frequent replacements.

Automation equipment benefits from 305SZZST-W64 Bearing’s consistent performance in robotic arms and assembly lines. The metric sizing ensures compatibility with a variety of industrial machinery.
