Single Row Deep Groove Ball Bearings 217SZZX

Single Row Deep Groove Ball Bearings 217SZZX

The 217SZZX is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from robust chrome steel for durability. It supports radial loads up to 21762 lbf and operates smoothly at speeds up to 4800 RPM.

Its shielded design keeps contaminants out while maintaining smooth rotation, and the chrome steel cage enhances longevity. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. It’s well-suited for applications like electric motors or pumps where radial load handling is key.

Weighing 1.95kg, it’s a sturdy choice for industrial use. Compliant with RoHS and REACH standards, ensuring safety and environmental friendliness.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 217SZZX
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 21762 lbf
  • Static Radial Load 22481 lbf
  • Max Speed 4800 rpm
  • Weight 1.95 kg
  • price（$） 78.399
Single Row Deep Groove Ball Bearings 217SZZX dimension drawing
Download DWG Download PDF

Features

Performance Features of 217SZZX Bearing

217SZZX Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 21762 lbf, ensuring reliable performance in various applications.

The shielded design of 217SZZX Bearing protects against contaminants, extending its service life.
With a maximum speed of 4,800 rpm, it balances durability and efficiency for smooth operation.

217SZZX Bearing operates effectively in temperatures ranging from -30° to 120°C.
Its ABEC 1 tolerance class ensures consistent performance in precision tasks.

Application

Industrial Uses of 217SZZX Bearing
217SZZX Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

Where Is 217SZZX Bearing Used?
You’ll often find 217SZZX Bearing in automotive applications such as alternators and wheel hubs. Its radial load capacity makes it a reliable choice for smooth, long-lasting performance.

Perfect Fit for Automation: 217SZZX Bearing
217SZZX Bearing works well in automated systems like conveyor belts, thanks to its consistent operation under radial loads. The ABEC 1 tolerance ensures reliable performance without overcomplicating maintenance.

Medical vs Industrial: Where 217SZZX Bearing Excels
In medical devices like centrifuges, 217SZZX Bearing offers quiet and precise rotation. For industrial gearboxes, its robust build handles heavier loads with ease.

Key Fields for 217SZZX Bearing
217SZZX Bearing is a go-to for household appliances like washing machines, where its shielded design protects against dust and moisture. The wide temperature range also suits various climates.
