Single Row Deep Groove Ball Bearings 217SZ

Single Row Deep Groove Ball Bearings 217SZ

The 217SZ is a single-row deep groove ball bearing with an 85mm bore and 150mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 21762 lbf and operates smoothly at speeds up to 4800 RPM.

Its shielded design offers basic protection against dust and debris, while the chrome steel cage ensures durability. The bearing functions well in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1.95kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe and dependable option for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 217SZ
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 28 mm
  • Width Tolerance -0.2mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 21762 lbf
  • Static Radial Load 22481 lbf
  • Max Speed 4800 rpm
  • Weight 1.95 kg
  • price（$） 44.667
Single Row Deep Groove Ball Bearings 217SZ dimension drawing
Download DWG Download PDF

Features

Performance Features of 217SZ Bearing

217SZ Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 21762 lbf, ensuring steady performance in various applications.
The shielded design protects against contaminants, enhancing durability in harsh environments.
With a maximum speed of 4,800 rpm, it balances reliability and efficiency for everyday use.

Application

Industrial Uses of 217SZ Bearing
217SZ Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures durability in demanding environments.

Where Is 217SZ Bearing Used?
You’ll find 217SZ Bearing in automotive applications such as alternators and wheel hubs, thanks to its reliable radial load capacity. Its metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 217SZ Bearing
In automated systems, 217SZ Bearing works well in conveyor belts and robotic arms, providing smooth operation. The ABEC 1 tolerance ensures consistent performance without unnecessary complexity.

Medical vs Industrial: Where 217SZ Bearing Excels
While 217SZ Bearing handles industrial equipment like compressors, it’s also suitable for medical devices requiring steady rotation. The wide temperature range allows it to perform in different settings.

Light-Duty vs Heavy-Duty: Best Uses for 217SZ Bearing
For lighter tasks, 217SZ Bearing fits well in household appliances like washing machines. In heavier applications, it supports machinery like gearboxes, balancing load and speed effectively.
