Single Row Deep Groove Ball Bearings 213MFF

Single Row Deep Groove Ball Bearings 213MFF

The 213MFF is a single row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel for reliable performance. It handles radial loads up to 13601 lbf and operates smoothly at speeds up to 6000 RPM.

Its open design allows for easy lubrication, while the chrome steel cage ensures durability under heavy use. The bearing works efficiently in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 1.05kg, it offers a robust build for industrial use. Compliant with RoHS and REACH standards for safe and eco-friendly operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 213MFF
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 13601 lbf
  • Static Radial Load 13151 lbf
  • Max Speed 6000 rpm
  • Weight 1.05 kg
  • price（$） 26.604
Single Row Deep Groove Ball Bearings 213MFF dimension drawing
Download DWG Download PDF

Features

How Does 213MFF Bearing Reduce Friction?

213MFF Bearing features a deep groove design, optimised for radial load distribution and smooth operation.
Its chrome steel construction ensures durability while minimising friction during high-speed rotations.
The open seal type allows for easy lubrication, enhancing performance in various conditions.
With a maximum speed of 6,000 rpm, it delivers reliable efficiency for industrial applications.

Core Advantages of 213MFF Bearing

213MFF Bearing is built with chrome steel rings and balls, offering excellent resistance to wear.
Its dynamic radial load capacity of 13601 lbf ensures stable performance under heavy loads.
The ABEC 1 tolerance class provides consistent precision for general industrial use.
Operating within -30°C to 120°C, it adapts well to diverse temperature conditions.

Why Choose 213MFF Bearing for Precision Tasks?

213MFF Bearing’s single-row design ensures accurate radial load handling with minimal deflection.
The chrome steel cage maintains ball alignment, reducing noise and vibration during operation.
Its static radial load capacity of 13151 lbf makes it suitable for demanding applications.
Weighing just 1.05 kg, it balances strength and ease of handling.

Application

Industrial Uses of 213MFF Bearing
213MFF Bearing is commonly used in industrial machinery like pumps and electric motors, where its radial load capacity ensures smooth operation. The open design allows for easy lubrication, extending its service life in demanding conditions.

In automotive applications, 213MFF Bearing fits well in wheel hubs and transmission systems, providing reliable performance under constant radial loads. Its chrome steel construction offers durability, making it suitable for long-term use in vehicles.

For automation equipment, 213MFF Bearing supports precise movements in robotic arms and conveyor belts. The ABEC 1 tolerance ensures consistent performance, even in high-speed scenarios.

In household appliances like washing machines, 213MFF Bearing reduces friction and noise, enhancing user comfort. Its metric sizing makes it compatible with a variety of European and Asian models.
