Single Row Deep Groove Ball Bearings 213M

Single Row Deep Groove Ball Bearings 213M

The 213M is a single-row deep groove ball bearing with a 65mm bore and 120mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 13601 lbf and operates smoothly at speeds up to 6000 RPM.

Its open design simplifies maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a cost-effective alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are predominant.

Weighing 1.05kg, it balances strength and manageability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 213M
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.15mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 13601 lbf
  • Static Radial Load 13151 lbf
  • Max Speed 6000 rpm
  • Weight 1.05 kg
  • price（$） 22.491
Single Row Deep Groove Ball Bearings 213M dimension drawing
Download DWG Download PDF

Features

Why Choose 213M Bearing for Precision Tasks?

213M Bearing features a single row deep groove design, optimised for radial load handling with a dynamic capacity of 13601 lbf.

Its chrome steel construction ensures durability and resistance to wear in various operating conditions.

The ABEC 1 tolerance class guarantees consistent performance for precision applications.

With a maximum speed of 6,000 rpm, it maintains efficiency while handling demanding tasks.

Application

Common Applications of 213M Bearing
213M Bearing is widely used in industrial machinery, such as pumps and electric motors, where its radial load capacity ensures reliable performance. The open design allows for easy lubrication, making it suitable for continuous operation.

In automotive applications, 213M Bearing fits well in wheel hubs and alternators, providing smooth rotation under varying loads. Its chrome steel construction offers durability, even in demanding driving conditions.

For automation systems, 213M Bearing supports robotic arms and conveyor belts, where precision and longevity are key. The ABEC 1 tolerance ensures consistent performance in repetitive tasks.

Around the home, 213M Bearing can be found in appliances like washing machines, where its robust design handles daily wear and tear. The metric sizing makes it compatible with a variety of household devices.
